84
(Note)
• All parts are supplied from PHAAM, Malaysia (Vendor Code: 061).
• “O” marked parts are recommended to be kept in stock.
[PHAAM] Printed in Malaysia
SFYW0701-00
REF. NO. DESCRIPTION & NAME QTY. CU-E15GKE CU-E15GKE-3 REMARKS
1 CHASSY ASS’Y 1 CWD50K2085 ←
2 ANTI-VIBRATION BUSHING 3 CWH50077 ←
3 COMPRESSOR 1 5CS130XAD04 ← O
4 NUT-COMPRESSOR MOUNT 3 CWH56000J ←
5 SOUND PROOF MATERIAL 1 CWG302302 ←
6 FAN MOTOR BRACKET 1 CWD541084 ←
7 FAN MOTOR 1 CWA981166J ← O
8 SCREW - FAN MOTOR BRACKET 2 CWH551198 ←
9 SCREW - FAN MOTOR MOUNT 3 CWH551106J ←
10 PROPELLER FAN ASSY 1 CWH03K1016 ←
11 NUT - PROPELLER FAN 1 CWH56053J ←
12 CONDENSER 1 CWB32C2053 ←
14 TUBE ASS’Y COMPLETE 1 CWT023679 ← O
15 4 WAYS VALVE 1 CWB001026J ←
18 HOLDER - COUPLING 1 CWH351056 ←
19 3 WAYS VALVE (GAS) 1 CWB011361 ← O
20 2 WAYS VALVE (LIQUID) 1 CWB021292 ← O
22 SOUND PROOF BOARD 1 CWH151050 ←
23 TERMINAL COVER 1 CWH171039A ←
24 NUT-TERMINAL COVER 1 CWH7080300J ←
25 SENSOR COMPLETE (COMP. TOP) 1 CWA50C2185 ←
26 HOLDER SENSOR 1 CWH321010 ←
27 V-COIL COMPLETE (4-WAYS VALVE) 1 CWA43C2168J ←
28 V-COIL COMPLETE (EXPAND VALVE) 1 CWA43C2058J ←
29 SENSOR COMPLETE (COMP. DISC.) 1 CWA50C2180 ←
30 SENSOR COMPLETE 1 CWA50C2181 ←
31 REACTOR 1 CWA421069 ←
32 CONTROL BOARD CASING (SIDE) 1 CWH102273 ←
33 TERMINAL BOARD ASSY 1 CWA28K1110J ←
34 FUSE HOLDERS 1 K3GB1PH00016 ←
35 FUSE 1 K5D303BBA002 ←
37 CONTROL BOARD CASING (BOTTOM) 1 CWH102282 ←
38 ELECTRONIC CONTROLLER - MAIN 1 CWA73C2583R CWA73C2736R O
40 CONTROL BOARD COVER (TOP) 1 CWH131167 ←
41 CABINET SIDE PLATE (LEFT) 1 CWE041255A ←
42 HANDLE 1 CWE161010 ←
43 CABINET SIDE PLATE (RIGHT) 1 CWE041158A ←
44 HANDLE 2 CWE16000E ←
45 CABINET FRONT PLATE CO. 1 CWE06K1043 ←
46 WIRE NET 1 CWD041041A ←
47 CABINET TOP PLATE 1 CWE031031A ←
48 CONTROL BOARD COVER (BOTTOM) 1 CWH131168 ←
49 CONTROL BOARD COVER (TOP) 1 CWH131169A ←
50 OPERATING INSTRUCTION 1 CWF565491 ←
52 INSTALLATION INSTRUCTION 1 CWF613080 ←
56 DRAIN HOSE 1 CWH5850080 ←
57 PACKING 1 CWB81012 ←
58 SOUND PROOF MATERIAL 1 CWG302290
←
59 SOUND PROOF MATERIAL 1 CWG302301 ←
60 OPERATING INSTRUCTION 1 CWF565492 ←
61 OPERATING INSTRUCTION 1 CWF565493 ←
62 INSTALLATION INSTRUCTION 1 CWF613081 ←
63 INSTALLATION INSTRUCTION 1 CWF613087 ←
