Panasonic CS-E15LKEW Service Manual

171
18.2. Sensible Capacity Chart
O CU-E7LKE CU-E7LKE-3
O CU-E9LKE CU-E9LKE-3
O CU-E12LKE
O CU-E12LKE-3
O CU-E15LKE
230V Outdoor Temp. (°C)
Indoor wet
bulb temp.
30 35 40 46
TC SHC IP TC SHC IP TC SHC IP TC SHC IP
17.0°C 2.03 1.54 0.43 1.90 1.48 0.46 1.77 1.42 0.50 1.61 1.35 0.53
19.0°C 2.05 0.47
19.5°C 2.23 1.61 0.44 2.09 1.55 0.47 1.94 1.49 0.50 1.77 1.42 0.54
22.0°C 2.43 1.67 0.45 2.27 1.61 0.48 2.12 1.55 0.51 1.92 1.48 0.55
230V Outdoor Temp. (°C)
Indoor wet
bulb temp.
30 35 40 46
TC SHC IP TC SHC IP TC SHC IP TC SHC IP
17.0°C 2.48 1.88 0.49 2.32 1.80 0.53 2.16 1.73 0.57 1.96 1.65 0.61
19.0°C 2.50 0.54
19.5°C 2.72 1.97 0.50 2.55 1.89 0.54 2.37 1.82 0.58 2.15 1.73 0.63
22.0°C 2.97 2.04 0.51 2.77 1.96 0.55 2.58 1.89 0.59 2.35 1.81 0.64
230V Outdoor Temp. (°C)
Indoor wet
bulb temp.
30 35 40 46
TC SHC IP TC SHC IP TC SHC IP TC SHC IP
17.0°C 3.47 2.63 0.79 3.24 2.52 0.85 3.02 2.43 0.91 2.74 2.30 0.98
19.0°C 3.50 0.86
19.5°C 3.81 2.76 0.80 3.56 2.65 0.86 3.31 2.55 0.92 3.01 2.43 1.00
22.0°C 4.15 2.86 0.82 3.88 2.75 0.88 3.61 2.65 0.94 3.28 2.53 1.01
230V Outdoor Temp. (°C)
Indoor wet
bulb temp.
30 35 40 46
TC SHC IP TC SHC IP TC SHC IP TC SHC IP
17.0°C 3.47 2.63 0.83 3.24 2.52 0.90 3.02 2.43 0.96 2.74 2.30 1.03
19.0°C 3.50 0.91
19.5°C 3.81 2.76 0.85 3.56 2.65 0.91 3.31 2.55 0.98 3.01 2.43 1.05
22.0°C 4.15 2.86 0.86 3.88 2.75 0.93 3.61 2.65 0.99 3.28 2.53 1.07
230V Outdoor Temp. (°C)
Indoor wet
bulb temp.
30 35 40 46
TC SHC IP TC SHC IP TC SHC IP TC SHC IP
17.0°C 4.17 3.16 1.15 3.89 3.03 1.24 3.62 2.91 1.33 3.29 2.77 1.43
19.0°C 4.20 1.26
19.5°C 4.57 3.31 1.18 4.28 3.18 1.27 3.98 3.06 1.35 3.62 2.91 1.46
22.0°C 4.99 3.43 1.20 4.66 3.30 1.29 4.33 3.18 1.38 3.94 3.03 1.49

Panasonic CS-E15LKEW Specifications

General

Thermostat range	- °C
Hose length (max)	15 m
Remotely operated	Yes
Cooling capacity (max)	3610 BTU/h
Dehumidifying capacity	2.4 l/h
Heating capacity (max)	4640 BTU/h
Cooling capacity in watts (max)	4200 W
Heating capacity in watts (max)	5400 W
Cooling energy efficiency (EER, W/W)	3.44
Heating energy efficiency (COP, W/W)	3.68
Indoor unit type	Wall-mountable
Airflow	750 m³/h
Noise level	59 dB
Power requirements	230 V

Weight and Dimensions

Weight	9000 g
Dimensions (WxDxH)	780 x 204 x 290 mm
