Panasonic CS-E15LKEW Service Manual

180
(Note)
• All parts are supplied from PHAAM, Malaysia (Vendor Code: 00029488).
• “O” marked parts are recommended to be kept in stock.
56 ELECTRONIC CONTROLLER - COMPARATOR 1 CWA745790 ←←←O
57 ELECTRONIC CONTROLLER - ECO PATROL 1 CWA745791 ←←←O
58 COVER FOR PCB ECO (UPPER) 1 CWD933192 ←←←O
59 COVER FOR PCB ECO (BOTTOM) 1 CWD933193 ←←←O
60 LEAD WIRE - PCB ECO 1 CWA67C8484 ←←←O
61 SENSOR COMPLETE (ECO) 1 CWA50C2709 ←←←O
62 COVER FOR RECEIVER (UPPER) 1 CWD933022 ←←←O
63 COVER FOR RECEIVER (BOTTOM) 1 CWD933209 ←←←O
64 OPERATING INSTRUCTION 1 CWF567265 ←←←
65 INSTALLATION INSTRUCTION 1 CWF614211 ←←←
REF
NO.
PART NAME & DESCRIPTION QTY. CS-E18LKEW CS-E21LKEW CS-XE18LKEW CS-XE21LKEW REMARKS

Panasonic CS-E15LKEW Specifications

General

Thermostat range	- °C
Hose length (max)	15 m
Remotely operated	Yes
Cooling capacity (max)	3610 BTU/h
Dehumidifying capacity	2.4 l/h
Heating capacity (max)	4640 BTU/h
Cooling capacity in watts (max)	4200 W
Heating capacity in watts (max)	5400 W
Cooling energy efficiency (EER, W/W)	3.44
Heating energy efficiency (COP, W/W)	3.68
Indoor unit type	Wall-mountable
Airflow	750 m³/h
Noise level	59 dB
Power requirements	230 V

Weight and Dimensions

Weight	9000 g
Dimensions (WxDxH)	780 x 204 x 290 mm
