17
Indoor CS-E18NKEW, CS-XE18NKEW CS-E21NKEW, CS-XE21NKEW
Model
Outdoor CU-E18NKE CU-E21NKE
Performance Test Condition EUROVENT EUROVENT
Phase, Hz Single, 50 Single, 50
Power Supply
V 230 230
Min. Mid. Max. Min. Mid. Max.
kW 0.98 5.00 6.00 0.98 6.30 7.10
BTU/h 3340 17100 20500 3340 21500 24200
Capacity
Kcal/h 840 4300 5160 840 5420 6110
Running Current A - 6.6 - - 9.9 -
Input Power W 280 1.47k 2.03k 280 2.21k 2.54k
Annual Consumption kWh - 735 - - 1105 -
W/W 3.50 3.40 2.96 3.50 2.85 2.80
BTU/hW 11.93 11.63 10.10 11.93 9.73 9.53
EER
Kcal/hW 3.00 2.93 2.54 3.00 2.45 2.41
Power Factor % - 97 - - 97 -
dB-A 44 / 37 / 34 45 / 37 / 34
Indoor Noise (H / L / QLo)
Power Level dB 60 / - 61 / -
dB-A 47 / - 48 / -
Cooling
Outdoor Noise (H / L)
Power Level dB 61 / - 62 / -
kW 0.98 5.80 8.00 0.98 7.20 8.50
BTU/h 3340 19800 27300 3340 24600 29000
Capacity
Kcal/h 840 4990 6880 840 6190 7310
Running Current A - 6.9 - - 9.4 -
Input Power W 340 1.54k 2.60k 340 2.10k 2.75k
W/W 2.88 3.77 3.08 2.88 3.43 3.09
BTU/hW 9.82 12.86 10.50 9.82 11.71 10.55
COP
Kcal/hW 2.47 3.24 2.65 2.47 2.95 2.66
Power Factor % - 97 - - 97 -
dB-A 44 / 37 / 34 45 / 37 / 34
Indoor Noise (H / L / QLo)
Power Level dB 60 / - 61 / -
dB-A 47 / - 49 / -
Heating
Outdoor Noise (H / L)
Power Level dB 61 / - 63 / -
Low Temp. : Capacity (kW) / I.Power (W) / COP 5.80 / 2.35k / 2.47 6.16 / 2.43k / 2.53
Extr Low Temp. : Capacity (kW) / I.Power (W) / COP 4.98 / 2.41k / 2.07 5.24 / 2.54k / 2.06
Max Current (A) / Max Input Power (W) 11.4 / 2.60k 12.1 / 2.75k
Starting Current (A) 6.9 9.9
Type Hermetic Motor (Rotary) Hermetic Motor (Rotary)
Motor Type Brushless (4-poles) Brushless (4-poles)
Compressor
Output Power W 900 900
