18
Type Cross-Flow Fan Cross-Flow Fan
Material ASG20K1 ASG20K1
Motor Type Transistor (8-poles) Transistor (8-poles)
Input Power W 94.8 94.8
Output Power W 40 40
Cool rpm 880 880
QLo
Heat rpm 990 960
Cool rpm 960 970
Lo
Heat rpm 1070 1040
Cool rpm 1080 1145
Me
Heat rpm 1190 1240
Cool rpm 1200 1320
Hi
Heat rpm 1310 1440
Cool rpm 1390 1460
Indoor Fan
Speed
SHi
Heat rpm 1430 1480
Type Propeller Fan Propeller Fan
Material PP PP
Motor Type Induction (6-poles) Induction (6-poles)
Input Power W - -
Output Power W 40 40
Cool rpm 640 700
Outdoor Fan
Speed Hi
Heat rpm 640 680
Moisture Removal L/h (Pt/h) 2.8 (5.9) 3.5 (7.4)
Cool m
3
/min (ft
3
/min) 11.40 (403) 10.60 (374)
QLo
Heat m
3
/min (ft
3
/min) 13.00 (459) 11.20 (395)
Cool m
3
/min (ft
3
/min) 12.65 (447) 11.95 (422)
Lo
Heat m
3
/min (ft
3
/min) 14.25 (503) 12.40 (437)
Cool m
3
/min (ft
3
/min) 14.45 (510) 14.60 (516)
Me
Heat m
3
/min (ft
3
/min) 16.05 (567) 15.45 (546)
Cool m
3
/min (ft
3
/min) 16.3 (575) 17.3 (610)
Hi
Heat m
3
/min (ft
3
/min) 17.9 (630) 18.5 (655)
Cool m
3
/min (ft
3
/min) 18.1 (639) 19.1 (675)
Indoor
Airflow
SHi
Heat m
3
/min (ft
3
/min) 18.5 (653) 19.4 (685)
Cool m
3
/min (ft
3
/min) 39.2 (1385) 41.7 (1470)
Outdoor
Airflow
Hi
Heat m
3
/min (ft
3
/min) 37.9 (1340) 40.4 (1425)
Control Device Expansion Valve Expansion Valve
Refrigerant Oil cm
3
FV50S (450) FV50S (450)
Refrigeration
Cycle
Refrigerant Type g (oz) R410A, 1.22k (43.1) R410A, 1.28k (45.2)
Height(I/D / O/D) mm (inch) 290 (11-7/16) / 695 (27-3/8) 290 (11-7/16) / 695 (27-3/8)
Width (I/D / O/D) mm (inch) 1070 (42-5/32) / 875 (34-15/32) 1070 (42-5/32) / 875 (34-15/32)
Dimension
Depth (I/D / O/D) mm (inch) 240 (9-15/32) / 320 (12-5/8) 240 (9-15/32) / 320 (12-5/8)
Weight Net (I/D / O/D) kg (lb) 12 (26) / 46 (101) 12 (26) / 47 (104)
Pipe Diameter (Liquid / Gas) mm (inch) 6.35 (1/4) / 12.70 (1/2) 6.35 (1/4) / 12.70 (1/2)
Standard length m (ft) 5.0 (16.4) 5.0 (16.4)
Length range (min – max) m (ft) 3 (9.8) ~ 20 (65.6) 3 (9.8) ~ 20 (65.6)
I/D & O/D Height different m (ft) 15.0 (49.2) 15.0 (49.2)
Additional Gas Amount g/m (oz/ft) 20 (0.2) 20 (0.2)
Piping
Length for Additional Gas m (ft) 7.5 (24.6) 7.5 (24.6)
