Applicable piping kit
CZ-4F5, 7, 10AN (E18CK, E21CK)
SELECT THE BEST LOCATION
INDOOR UNIT
- There should not be any heat source or steam near the unit.
- There should not be any obstacles blocking the air circulation.
- A place where air circulation in the room is good.
- A place where drainage can be easily done.
- A place where noise prevention is taken into consideration.
- Do not install the unit near the door way.
- Ensure the spaces indicated by arrows from the wall, ceiling, fence
or other obstacles.
- Recommended installation height for indoor unit shall be at least
2.3 m.
OUTDOOR UNIT
- If an awning is built over the unit to prevent direct sunlight or rain,
be careful that heat radiation from the condenser is not
obstructed.
- There should not be any animal or plant which could be affected by
hot air discharged.
- Keep the spaces indicated by arrows from wall, ceiling, fence or
other obstacles.
