15 Replacement Parts List (Indoor Unit)
15.1. CS-E24DKE
REF. NO. PART NAME & DESCRIPTION QTY. CS-E24DKE REMARKS
1 CHASSY COMPLETE 1 CWD50C1382
2 FAN MOTOR 1 CWA981056 0
3 CROSS FLOW FAN COMPLETE 1 CWH02C1010
4 SCREW - CROSS FLOW FAN 1 CWH4580304
5 BEARING ASS’Y 1 CWH64K007
6 EVAPORATOR 1 CWB30C1678
7 FLARE NUT 1 CWT25086 (1/4”)
8 FLARE NUT 1 CWT251016 (5/8”)
9 HOLDER SENSOR 1 CWH32143
10 DISCHARGE GRILLE COMPLETE 1 CWE20C2441
11 VERTICAL VANE 15 CWE241088
12 CONNECTING BAR 1 CWE261025
13 AIR SWING MOTOR 1 CWA98260 0
13a LEAD WIRE - AIR SWING MOTOR 1 CWA67C3849
14 AIR SWING MOTOR 1 CWA98K1008 0
15 LEAD WIRE - AIR SWING MOTOR 1 CWA67C3731
16 HORIZONTAL VANE 1 CWE241152A
17 HORIZONTAL VANE 1 CWE241153A
18 CAP - DRAIN TRAY 1 CWH52C1001
19 BACK COVER CHASSIS 1 CWD932162B
20 CONTROL BOARD CASING 1 CWH102250
21 TERMINAL BOARD COMPLETE 1 CWA28C2082 0
22 POWER SUPPLY CORD 1 CWA20C2328
23 ELECTRONIC CONTROLLER - MAIN 1 CWA73C1770 0
23a ELECTRONIC CONTROLLER - POWER 1 CWA743304 0
24 INDICATOR & RECEIVER COMPLETE 1 CWE39C1116 0
25 INDICATOR HOLDER 1 CWD932435
26 INDICATOR HOLDER 1 CWD932436
27 SENSOR COMPLETE 1 CWA50C2122 0
28 CONTROL BOARD TOP COVER 1 CWH131209
29 CONTROL BOARD FRONT COVER 1 CWH131210
30 REMOTE CONTROL COMPLETE 1 CWA75C2616 0
31 FRONT GRILLE COMPLETE 1 CWE11C3160 0
32 INTAKE GRILLE COMPLETE 1 CWE22C1159
33 GRILLE DOOR 1 CWE141076
34 AIR FILTER (L) 1 CWD001137
35 AIR FILTER (R) 1 CWD001138
36 SCREW - FRONT GRILLE 3 XTT4+16C
37 CAP - FRONT GRILLE 3 CWH521062A
38 DRAIN HOSE 1 CWH851063
39 BAG COMPLETE - INSTALLATION SCREW 1 CWH82C067
40 INSTALLATION PLATE 1 CWH36K1007
41 FULCRUM 2 CWH621047
42 ELECTRONIC CONTROLLER - IONIZER 1 CWA743675 0
43 CASING - IONIZER 1 CWD932464
44 CASING - IONIZER 1 CWD932527
45 ION - GENERATOR 1 CWH94C0001
46 SUPERSONIC AIR PURIFYING DEVICE 1 CWH91C1013
47 ELEC.CONTROLLER-SUPERSONIC 1 CWA743874 0
48 SUPER ALLERU BUSTER FILTER 1 CWD00C1133 0
49 FRAME FR AIR FILTER SUPERSONIC 1 CWD011026
50 FRAME FR AIR FILTER SUPERSONIC 1 CWD011027
(Note)
•
All parts are supplied from PHAAM, Malaysia (Vendor Code: 061).
•
“O” marked parts are recommended to be kept in stock.
80
CS-E24DKE CU-E24DKE
