Panasonic CS-E24DKE - 17 Replacement Parts List (Outdoor Unit); 17.1. CU-E24 DKE

17 Replacement Parts List (Outdoor Unit)
17.1. CU-E24DKE
REF NO. DESCRIPTION & NAME QTY. CU-E24DKE REMARKS
1 CHASSY ASSY 1 CWD50K2098
2 ANTI-VIBRATION BUSHING 3 CWH501061
3 COMPRESSOR 1 C-7RVN153H0V O
4 NUT-COMPRESSOR MOUNT 3 CWH56000
5 SOUND PROOF MATERIAL 1 CWG302215
6 FAN MOTOR BRACKET 1 CWD541067
7 FAN MOTOR 1 CWA981111 O
8 SCREW - FAN MOTOR BRACKET 2 CWH551060
9 SCREW - FAN MOTOR MOUNT 3 CWH551106
10 PROPELLER FAN ASSY 1 CWH03K1016
11 NUT - PROPELLER FAN 1 CWH56053
12 CONDENSER 1 CWB32C1666
14 TUBE ASS’Y COMPLETE (CAP. TUBE & STRAINER) 1 CWT023184 O
15 4 WAYS VALVE 1 CWB001026
18 HOLDER - COUPLING 1 CWH351036
19 3 WAYS VALVE (GAS) 1 CWB011223 O
20 2 WAYS VALVE (LIQUID) 1 CWB021183 O
21 OIL SEPERATOR ASS’Y 1 CWB16K1011 O
22 SOUND PROOF BOARD 1 CWH151069
23 TERMINAL COVER 1 CWH171033
24 NUT-TERMINAL COVER 1 CWH561040
26 HOLDER SENSOR 3 CWH321026
27 V-COIL COMPLETE (4-WAYS VALVE) 1 CWA43C2168 O
28 V-COIL COMPLETE (EXPAND VALVE) 1 -
30 SENSOR COMPLETE 1 CWA50C2181 O
31 REACTOR 1 CWA421077
32 CONTROL BOARD (SIDE) 1 CWH102122
33 TERMINAL BOARD ASSY 1 CWA28K1036 O
34 FUSE HOLDERS 1 K3GB1PH00016
35 FUSE 1 K5D303BBA002
36 CONTROL BOARD (TOP) 1 CWH102204
37 CONTROL BOARD (BOTTOM) 1 CWH102205
38 ELECTRONIC CONTROLLER - MAIN 1 CWA73C1777R O
40 CONTROL BOARD COVER (TOP) 1 CWH131167
41 CABINET SIDE PLATE (LEFT) 1 CWE041082A
42 HANDLE 1 CWE161010
43 CABINET SIDE PLATE (RIGHT) 1 CWE041100A
44 HANDLE 2 CWE16000E
45 CABINET FRONT PLATE CO. 1 CWE06K1043
46 WIRE NET 1 CWD041041A
47 CABINET TOP PLATE 1 CWE031037A
48 CONTROL BOARD COVER (BOTTOM) 1 CWH131168
49 CONTROL BOARD COVER (TOP) 1 CWH131169A
50 OPERATING INSTRUCTION (ENG., ESP., ITA., NED., POR.,
GRE. & BUL.)
1 CWF564611
51 OPERATING INSTRUCTION (FRA., DEU., SWE. & NOR.) 1 CWF564612
52 INSTALLATION INSTRUCTION (ENG., FRA., ESP. & DEU.) 1 CWF612726
53 INSTALLATION INSTRUCTION (ITA., NED., POR. & GRE.) 1 CWF612727
54 INSTALLATION INSTRUCTION (BUL.) 1 CWF612728
55 INSTALLATION INSTRUCTION (SWE. & NOR) 1 CWF612729
56 DRAIN HOSE 1 CWH5850080
57 PACKING 1 CWB81012
58 SOUND PROOF MATERIAL 1 CWG302231
59 SOUND PROOF MATERIAL 1 CWG302233
60 SENSOR 1 CWA501114
61 LEAD WIRE 1 CWA67C5008
(Note)
•
All parts are supplied from PHAAM, Malaysia (Vendor Code: 061).
•
“O” marked parts are recommended to be kept in stock.
82
CS-E24DKE CU-E24DKE
