17
MODEL INDOOR CS-E15JKEW, CS-XE15JKEW
OUTDOOR CU-E15JKE-1
Performance Test Condition EUROVENT
Power Supply
Phase, Hz Single, 50
V 230
Min. Mid. Max.
Cooling
Capacity
kW 0.80 4.20 5.00
BTU/h 2730 14300 17100
Kcal/h 690 3610 4300
Running Current A — 5.7 —
Input Power W 195 1.26k 1.57k
Annual Consumption kWh — 630 —
EER
W/W 4.10 3.33 3.18
Kcal/hW 3.54 2.87 2.74
Power Factor % — 96 —
Indoor Noise (H / L / QLo)
dB-A 43 / 31 / 25
Power Level dB 59 / 47 / 41
Outdoor Noise (H / L)
dB-A 49 / -
Power Level dB 64 / -
Heating
Capacity
kW 0.80 5.30 6.80
BTU/h 2730 18100 23200
Kcal/h 690 4560 5850
Running Current A — 6.6 —
Input Power W 185 1.44k 1.94k
COP
W/W 4.32 3.68 3.51
Kcal/hW 3.73 3.17 3.02
Power Factor % — 95 —
Indoor Noise (H / L / QLo)
dB-A 43 / 35 / 32
Power Level dB 59 / 51 / 48
Outdoor Noise (H / L)
dB-A 51 / -
Power Level dB 66 / -
Low Temp. : Capacity (kW) / I.Power (W) / COP 4.92 / 1.72k / 2.86
Extr Low Temp. : Capacity (kW) / I.Power (W) / COP 3.94 / 1.83k / 2.15
Max Current (A) / Max Input Power (W) 9.0 / 1.94k
Starting Current (A) 6.6
Compressor
Type Hermetic Motor
Motor Type Brushless (6-poles)
Output Power W 700
Indoor Fan
Type Cross-flow Fan
Material ASG20K1
Motor Type Transistor (8-poles)
Input Power W —
Output Power W 40
Speed
QLo
Cool rpm 730
Heat rpm 1000
Lo
Cool rpm 870
Heat rpm 1080
Me
Cool rpm 1070
Heat rpm 1210
Hi
Cool rpm 1270
Heat rpm 1350
SHi
Cool rpm 1340
Heat rpm 1370
