18
Outdoor Fan
Type Propeller Fan
Material PP
Motor Type Induction (6-poles)
Input Power W 70
Output Power W 30
Speed Hi rpm 850
Moisture Removal L/h (Pt/h) 2.4 (5.1)
Indoor Airflow
QLo
Cool
m
3
/min (ft
3
/min)
6.0 (212)
Heat
m
3
/min (ft
3
/min)
9.2 (325)
Lo
Cool
m
3
/min (ft
3
/min)
7.7 (272)
Heat
m
3
/min (ft
3
/min)
10.2 (360)
Me
Cool
m
3
/min (ft
3
/min)
10.1 (357)
Heat
m
3
/min (ft
3
/min)
11.7 (413)
Hi
Cool
m
3
/min (ft
3
/min)
12.5 (440)
Heat
m
3
/min (ft
3
/min)
13.4 (475)
SHi
Cool
m
3
/min (ft
3
/min)
13.3 (470)
Heat
m
3
/min (ft
3
/min)
13.6 (480)
Outdoor Airflow Hi
Cool
m
3
/min (ft
3
/min)
31.4 (1110)
Heat
m
3
/min (ft
3
/min)
31.4 (1110)
Refrigeration Cycle
Control Device Check Valve & Capillary Tube
Refrigerant Oil
cm
3
RB68A or Freol Alpha 68M (320)
Refrigerant Type g (oz) R410A, 1010 (35.7)
Dimension Height (I/D / O/D) mm (inch) 290 (11-7/16) / 540 (21-9/32)
Width (I/D / O/D) mm (inch) 870 (34-9/32) / 780 (30-23/32)
Depth (I/D / O/D) mm (inch) 204 (8-1/16) / 289 (11-13/32)
Weight Net (I/D / O/D) kg (lb) 9 (20) / 34 (75)
Piping
Pipe Diameter (Liquid / Gas) mm (inch) 6.35 (1/4) / 12.7 (1/2)
Standard Length m (ft) 5 (16.4)
Length Range (min - max) m (ft) 3 (9.8) ~ 15 (49.2)
I/D & O/D Height Different m (ft) 15 (49.2)
Additional Gas Amount g/m (oz/ft) 20 (0.2)
Length for Additional Gas m (ft) 7.5 (24.6)
Drain Hose
Inner Diameter mm 16
Length mm 650
Indoor Heat
Exchanger
Fin Material Aluminium (Pre Coat)
Fin Type Slit Fin
Row x Stage x FPI 2 x 15 x 21
Size (W x H x L) mm 610 x 315 x 25.4
Outdoor Heat
Exchanger
Fin Material Aluminium
Fin Type Corrugated Fin
Row x Stage x FPI 2 x 24 x 17
Size (W x H x L) mm
36.4 x 504 x 713
684
Air Filter
Material Polypropelene
Type One-touch
Power Supply Outdoor Power Supply
Power Supply Cord A Nil
Thermostat Electronic Control
Protection Device Electronic Control
MODEL INDOOR CS-E15JKEW, CS-XE15JKEW
OUTDOOR CU-E15JKE-1
To Next Page
