8
MODEL INDOOR CS-E12JKEW, CS-XE12JKEW CS-E15JKEW, CS-XE15JKEW
OUTDOOR CU-E12JKE CU-E15JKE
Performance Test Condition EUROVENT EUROVENT
Power Supply
Phase, Hz Single, 50 Single, 50
V 230 230
Min. Mid. Max. Min. Mid. Max.
Cooling
Capacity
kW 0.80 3.50 4.00 0.90 4.20 5.00
BTU/h 2730 11900 13600 3070 14300 17100
Kcal/h 690 3010 3440 770 3610 4300
Running Current A — 4.1 — — 5.8 —
Input Power W 185 905 1.18k 215 1.22k 1.60k
Annual Consumption kWh — 453 — — 610 —
EER
W/W 4.32 3.87 3.39 4.19 3.44 3.13
Kcal/hW 3.73 3.33 2.92 3.58 2.96 2.69
Power Factor % — 96 — — 92 —
Indoor Noise (H / L / QLo)
dB-A 42 / 28 / 20 43 / 32 / 29
Power Level dB 58 / 44 / 36 59 / 48 / 45
Outdoor Noise (H / L)
dB-A 48 / - 46 / -
Power Level dB 63 / - 61 / -
Heating
Capacity
kW 0.80 4.40 6.70 0.90 5.40 7.10
BTU/h 2730 15000 22800 3070 18400 24200
Kcal/h 690 3780 5760 770 4640 6110
Running Current A — 5.1 — — 6.9 —
Input Power W 175 1.09k 1.93k 245 1.46k 2.21k
COP
W/W 4.57 4.04 3.47 3.67 3.70 3.21
Kcal/hW 3.94 3.47 2.98 3.14 3.18 2.76
Power Factor % — 93 — — 92 —
Indoor Noise (H / L / QLo)
dB-A 42 / 33 / 30 43 / 35 / 32
Power Level dB 58 / 49 / 46 59 / 51 / 48
Outdoor Noise (H / L)
dB-A 50 / - 46 / -
Power Level dB 65 / - 61 / -
Low Temp. : Capacity (kW) / I.Power (W) / COP 4.85 / 1.67k / 2.90 5.14 / 1.96k / 2.62
Extr Low Temp. : Capacity (kW) / I.Power (W) / COP 3.75 / 1.68k / 2.23 4.10 / 2.10k / 1.95
Max Current (A) / Max Input Power (W) 8.9 / 1.93k 9.7 / 2.21k
Starting Current (A) 5.1 6.9
Compressor
Type Hermetic Motor Hermetic Motor
Motor Type Brushless (6-poles) Brushless (4-poles)
Output Power W 700 900
Indoor Fan
Type Cross-flow Fan Cross-flow Fan
Material ASG20K1 ASG20K1
Motor Type Transistor (8-poles) Transistor (8-poles)
Input Power W — —
Output Power W 40 40
Speed
QLo
Cool rpm 630 730
Heat rpm 950 1000
Lo
Cool rpm 830 870
Heat rpm 1010 1080
Me
Cool rpm 1040 1070
Heat rpm 1150 1210
Hi
Cool rpm 1260 1270
Heat rpm 1300 1350
SHi
Cool rpm 1320 1340
Heat rpm 1340 1370
