Panasonic CS-E7JKEW Service Manual

9
Outdoor Fan
Type Propeller Fan Propeller Fan
Material PP PP
Motor Type Induction (6-poles) Transistor (8-poles)
Input Power W 70 —
Output Power W 30 40
Speed Hi rpm 830
Cool : 660
Heat : 640
Moisture Removal L/h (Pt/h) 2.0 (4.2) 2.4 (5.1)
Indoor Airflow
QLo
Cool
m
3
/min (ft
3
/min)
4.9 (173) 6.0 (212)
Heat
m
3
/min (ft
3
/min)
8.7 (307) 9.2 (325)
Lo
Cool
m
3
/min (ft
3
/min)
7.2 (254) 7.7 (272)
Heat
m
3
/min (ft
3
/min)
9.4 (332) 10.2 (360)
Me
Cool
m
3
/min (ft
3
/min)
9.7 (343) 10.1 (357)
Heat
m
3
/min (ft
3
/min)
11.0 (389) 11.7 (413)
Hi
Cool
m
3
/min (ft
3
/min)
12.5 (440) 12.5 (440)
Heat
m
3
/min (ft
3
/min)
12.8 (450) 13.4 (475)
SHi
Cool
m
3
/min (ft
3
/min)
13.1 (463) 13.3 (470)
Heat
m
3
/min (ft
3
/min)
13.3 (470) 13.6 (480)
Outdoor Airflow Hi
Cool
m
3
/min (ft
3
/min)
31.0 (1090) 48.5 (1710)
Heat
m
3
/min (ft
3
/min)
31.0 (1090) 46.8 (1650)
Refrigeration Cycle
Control Device Check Valve & Capillary Tube Expansion Valve
Refrigerant Oil
cm
3
RB68A or Freol Alpha 68M (320) RB68A or Freol Alpha 68M (400)
Refrigerant Type g (oz) R410A, 970 (34.2) R410A, 1.06k (37.4)
Dimension Height (I/D / O/D) mm (inch) 290 (11-7/16) / 540 (21-9/32) 290 (11-7/16) / 750 (29-17/32)
Width (I/D / O/D) mm (inch) 870 (34-9/32) / 780 (30-23/32) 870 (34-9/32) / 875 (34-15/32)
Depth (I/D / O/D) mm (inch) 204 (8-1/16) / 289 (11-13/32) 204 (8-1/16) / 345 (13-19/32)
Weight Net (I/D / O/D) kg (lb) 9 (20) / 34 (75) 9 (20) / 48 (106)
Piping
Pipe Diameter (Liquid / Gas) mm (inch) 6.35 (1/4) / 9.52 (3/8) 6.35 (1/4) / 12.70 (1/2)
Standard Length m (ft) 5 (16.4) 5 (16.4)
Length Range (min - max) m (ft) 3 (9.8) ~ 15 (49.2) 3 (9.8) ~ 15 (49.2)
I/D & O/D Height Different m (ft) 15.0 (49.2) 15.0 (49.2)
Additional Gas Amount g/m (oz/ft) 20 (0.2) 20 (0.2)
Length for Additional Gas m (ft) 7.5 (24.6) 7.5 (24.6)
Drain Hose
Inner Diameter mm 16 16
Length mm 650 650
Indoor Heat
Exchanger
Fin Material Aluminium (Pre Coat) Aluminium (Pre Coat)
Fin Type Slit Fin Slit Fin
Row x Stage x FPI 2 x 15 x 21 2 x 15 x 21
Size (W x H x L) mm 610 x 315 x 25.4 610 x 315 x 25.4
Outdoor Heat
Exchanger
Fin Material Aluminium Aluminium
Fin Type Corrugated Fin Corrugated Fin
Row x Stage x FPI 2 x 24 x 17 1 x 28 x 18
Size (W x H x L) mm
36.4 x 504 x 713
684
22 x 711 x 835
Air Filter
Material Polypropelene Polypropelene
Type One-touch One-touch
Power Supply Outdoor Power Supply Outdoor Power Supply
Power Supply Cord A Nil Nil
Thermostat Electronic Control Electronic Control
Protection Device Electronic Control Electronic Control
MODEL INDOOR CS-E12JKEW, CS-XE12JKEW CS-E15JKEW, CS-XE15JKEW
OUTDOOR CU-E12JKE CU-E15JKE
