Panasonic CS-F24DTE5 Service Manual

SCHEMA
TIC DIAGRAM 7/7
A
TIC DIAGRAM 7/7A
ELECTRONIC CONTROL UNIT
TABLE 1
CODE No. A743401 A743564 NOTE
R205 NONE 0.03Ω 5W
R206 17.4k 1% 16.9k 1%
R258 2.61k 1% 4.02k 1%
R260 33.2k 1% 13.7k 1%
R263 4.99k 1% 5.23k 1%
R264 4.99k 1% 5.23k 1%
FW-BLOCK1 NONE ←
DC
FW-BLOCK2 NONE ←
CN-FM3 VH3-2(GRN) ←
C31 0.01µ ←
SSR1 G3WC-202P ←
ZNR2 NONE ←
CN-FM4 NONE VH3-2(YLW)
C32 NONE 0.01µ
SSR2 NONE G3MC-202P
ZNR3 NONE ←
RY-V1 NONE ←
CN-V1 NONE ←
VALVE
CR1 NONE ←
RY-V2 NONE ←
CN-V2 NONE ← VALVE
CR2 NONE ←
CN-LPS1 NONE ←
C55 1µ 6.3V ←
AC-BLK A67C5179 A67C5217
AC-WHT A67C5180 A67C5218
U.V.W A28062 ←
R58 1.65k 1% NONE
R67 698Ω 1% 499Ω 1%
R68 0Ω 20.0K 1%
R69 NONE 20.0K 1%
PTC4 NONE 100Ω 280V
RY-PWR2 NONE ←
CN-RY2 NONE ←
CR4 NONE ←
D1 NONE ←
Q7 NONE ←
R273 NONE ←
R274 NONE ←
CN-RY1 NV2 ←
D27 1A5-E ←
Q5 RTIN432C ←
Q11 2SA1036K(R) ←
R183 4.7k ←
R272 2.2k ←
R43, R113, JP1 NONE ←
C25, C92 NONE ←
CN-CPU, CN-21 NONE ←
R253~R256, R278 NONE ←
R279 (JUMPER) ←
R118~R120 NONE ←
COM 1 A67C5494 A67C5507
COM 2 A67C5495 A67C5508
COM 3 A67C5496 A67C5509
REMARK
CU-L24DBE5 CU-L34DBE5
CU-L28DBE5 CU-L430DB5
IPM-TYPE
AC FM-TYPE
AC
DC
RYLAY
NO MOUNT
OTHER
ELECTRONIC CONTROL UNIT COMPLETE
TABLE 2
CODE No. A73C1598 A73C1600 NOTE
Q10 PS21865-A PS21867-A
HEATSINK A581074 A581086
DB S25VB60 S50VB60
ELECTRONIC
CONTROL UNIT A743401 A743564
(MAIN)
REMARK
CU-L24DBE5 CU-L34DBE5
CU-L28DBE5 CU-L430DB5
IPM-TYPE
POWER
ELECTRONIC CONTROL UNIT COMPLETE
TABLE 3
CODE No. A743403 A743566
CT300 NONE CT25UU-P
CT301 NONE ←
AC-IN NONE ←
AC-OUT NONE ←
CN-CT NONE XH3(VLW)
SW4 NONE ←
R328~R331 NONE ←
REMARK
CU-L24DBE5 CU-L34DBE5
CU-L28DBE5 CU-L430DB5
CT-TYPE
NO MOUNT
ELECTRONIC CONTROL UNIT COMPLETE
TABLE 4
CODE No. A743568 A743478
C209 800µ 400V 800µ 400V
REMARK
POWER
PRES,-SENSOR
CT-TYPE
CAPACITOR
2
2
2
2
CU-L34DBE5 CU-L43DBE5
106
CS-F24DB4E5 CU-L24DBE5 / CS-F28DB4E5 CU-L28DBE5
