3.1. Product Specification
3 Specification
3.1.1. CS-F24DB4E5 CU-L24DBE5
ITEM / MODEL Indoor Unit Outdoor Unit
Main Body CS-F24DB4E5 CU-L24DBE5
Panel CZ-BT03P
Remote CZ-RD513C (Wired)
Control CZ-RL513B (Wireless)
Cooling Capacity kW 6.3
BTU/h 21,500
Heating Capacity kW 7.1
BTU/h 24,200
Refrigerant Charge-less m 30
Standard Air Volume for High, m
3
/min Hi 18 Me 16 Lo 14 Hi 48
Medium and Low Speed cfm 636 562 488 1695
Outside Dimension (H x W x D) mm 246 x 840 x 840 795 x 900 x 320
inch 9-11/16 x 33-1/24 x 33-1/24 31-5/16 x 35-7/16 x 12-19/32
Net Weight kg (lbs) 26 (58) 71 (158)
Piping
Connection
Refrigerant Gas mm (inch) O.D Ø 15.88 (5/8) Flared Type
Liquid mm (inch) O.D Ø 9.53 (3/8) Flared Type
Drain mm O.DØ20 I.DØ20x1
Compressor Type, Number of Set - Hermetic - 2P (Rotary), 1
Starting Method - DC-INV control
Motor Type - 4-pole single phase brushless motor
Rated Output kW - 1.8
Fan Type, Number of Set Turbo fan-1 Propeller fan-1
Motor Type 8-pole single phase induction motor 6-pole single phase induction motor
Rated Output kW 0.04 0.07
Air-heat Exchanger (Row x Stage x FPI) Louver-fin type (2 x 10 x 20) Corrugate-fin type (2 x 36 x 19)
Refrigerant Control - Exp. Value
Refrigerant Oil (Charged) cm
3
- FV50S (800)
Refrigerant (Charged) R410A kg (oz) - 2.13 (75)
Running
Adjustment
Control Switch Wireless or Wired Remote Control -
Room Temperature Thermostat -
Safety Devices Internal protector for compressor, Internal thermostat for fan motor,
Crankcase heater, High pressure switch, Current transformer
Noise Level dB (A) Hi 36 Lo 32 Cooling 47, Heating 49
Power level dB Cooling : Hi 51 Lo 47
Heating : Hi 51 Lo 47
Cooling 63, Heating 65
Moisture Removal L/h (Pt/h) 3.6 (7.6)
EER W/W 3.71
COP W/W 3.86
1. Cooling capacities are based on indoor temperature of 27°C D.B. (80.6°F D.B.), 19.0°C W.B. (66.2°F W.B.) and outdoor air
temperature of 35°C D.B. (95°F D.B.), 24°C W.B. (75.2°F W.B.)
2. Heating capacities are based on indoor temperature 20°C D.B. (68°F D.B.) and outdoor air temperature of 7°C D.B. (44.6°F
D.B.), 6°C W.B. (42.8°F W.B.)
ELECTRICAL DATA (50 Hz)
ITEM / MODEL Condition by JIS-B8615
Volts V 220 230 240
Phase Single Single Single
Power Consumption kW Cool 1.70 1.70 1.70
Heat 1.84 1.84 1.84
Running Current A Cool 8.0 7.7 7.5
Heat 8.7 8.4 8.1
Starting Current A 8.7 8.4 8.1
Power Factor % Cool 97 96 94
Heat 96 95 95
*Power Factor means total figure of compressor, indoor fan motor and outdoor fan motor.
Panasonic Power source AC, 1~220V, 230V, 240V 50Hz
12
CS-F24DB4E5 CU-L24DBE5 / CS-F28DB4E5 CU-L28DBE5
