Earth lead wire shall be longer than other lead wires as shown in the figure for the electrical safety in case of the slipping out of the
cord from the anchorage.
•
• •
•
Power supply specifications
Model name Leakage
current
Circuit breaker
(Minimum Capacity)
Minimum
power
4mm
2
cable
Maximum
permissible
impedance
(
Ω
)
Indoor/outdoor
unit connection
breaker
(A)
Switch
(A)
Fuse
(A)
supply
cables
based on
length (m)
power cables
(terminals
, , , )
CU-L24DB*** 220V-240V~ 30 30 20
4mm
2
14 0.1
2.5 mm
2
×3
CU-L28DB*** 220V-240V~ 30 30 20 14 0.1
CU-L34DB*** 220V-240V~ 40 40 30 9 0.05
CU-L43DB*** 220V-240V~ 40 40 40 8 0.05
CU-L50DB*** 380V-415V
3N~
30 30 30 11 0.02
NOTE
1. Where ground work (earth) is carried out, do not connect the ground return to the gas pipe, water line pipe, grounded circuit of the
telephone and lightning rod, or ground circuit of other product in which earth leakage breaker is incorporated. (Such action is
prohibited by statute, etc.)
Make sure the indoor and outdoor connection wires are detangled. (There might be effect to received outside noise.)
2. Use the standard power supply cables for Europe (such as H05RN-F or H07RN-F which conforms to CENELEC (HAR) rating
specifications) or use the cables based on IEC standard. (245IEC57, 245IEC66)
3. Select the particular size of electrical wire for power supply cables in accordance with the standards of the given nation and
region.
56
CS-F24DB4E5 CU-L24DBE5 / CS-F28DB4E5 CU-L28DBE5
