Panasonic CS-F50DTE5 Service Manual

108
TC: Cooling Capacity
SHC: Sensible Heat Capacity
IPT: Cooling Power Consumption
Ambient Temperature Air Entering Condenser (°C D.B.)
Model Power Return 25°C30°C35°C40°C43°C
(CS-) Source Air TC SHC IPT TC SHC IPT TC SHC IPT TC SHC IPT TC SHC IPT
D.B. W.B. kW kW kW kW kW kW kW kW kW kW kW kW kW kW kW
F43DTE5 400V,
50Hz,
3 phase
17 13.01 8.52 3.89 12.50 8.44 4.22 11.76 8.17 4.59 10.88 7.83 5.04 10.24 7.58 5.34
23 19 13.74 7.01 4.13 13.31 7.06 4.47 12.63 6.95 4.87 11.78 6.71 5.34 11.18 6.60 5.66
22 15.01 5.40 4.46 14.60 5.55 4.83 13.93 5.57 5.26 13.04 5.48 5.77 12.42 5.46 6.11
17 12.86 9.84 3.90 12.36 9.70 4.21 11.64 9.37 4.58 10.80 9.02 5.01 10.19 8.71 5.31
25 19 13.76 8.67 4.15 13.28 8.63 4.48 12.57 8.42 4.88 11.70 8.13 5.33 11.09 7.93 5.65
22 15.00 6.82 4.48 14.54 6.91 4.84 13.83 6.85 5.27 12.88 6.63 5.75 12.30 6.58 6.10
17 12.70 11.30 3.90 12.22 11.12 4.20 11.53 10.72 4.58 10.72 10.29 4.97 10.14 10.04 5.27
27 19 13.78 10.19 4.17 13.25 10.07 4.49 12.50 9.75 4.89 11.63 9.42 5.32 11.00 9.13 5.63
22 14.99 8.24 4.50 14.48 8.25 4.85 13.73 8.10 5.28 12.75 7.78 5.74 12.19 7.68 6.08
17 12.67 12.42 3.88 12.22 12.10 4.20 11.50 11.50 4.52 10.80 10.80 4.86 10.27 10.27 5.06
29 19 13.75 11.68 4.14 13.25 11.53 4.48 12.50 11.13 4.83 11.72 10.72 5.19 11.14 10.47 5.41
22 14.93 9.78 4.57 14.42 9.73 4.94 13.64 9.48 5.32 12.77 9.19 5.71 12.18 9.01 5.95
17 12.66 12.40 3.86 12.22 12.22 4.19 10.69 10.69 4.49 10.86 10.86 4.78 10.35 10.35 4.92
32 19 13.73 13.59 4.13 13.25 13.25 4.48 12.51 12.51 4.79 11.78 11.78 5.10 11.23 11.23 5.26
22 14.89 12.21 4.61 14.38 12.08 5.00 13.62 11.71 5.35 12.78 11.37 5.70 12.18 11.08 5.87
F50DTE5 400V,
50Hz,
3 phase
17 14.05 9.21 4.20 13.50 9.11 4.55 12.70 8.83 4.96 11.75 8.46 5.44 11.06 8.18 5.77
23 19 14.84 7.57 4.46 14.38 7.62 4.82 13.64 7.50 5.26 12.72 7.25 5.76 12.07 7.12 6.11
22 16.21 5.83 4.81 15.77 5.99 5.21 15.05 6.02 5.68 14.08 5.91 6.23 13.41 5.90 6.60
17 13.89 10.62 4.21 13.35 10.48 4.55 12.58 10.12 4.95 11.66 9.74 5.40 11.00 9.41 5.73
25 19 14.86 9.36 4.48 14.34 9.32 4.84 13.57 9.09 5.27 12.64 8.78 5.75 11.98 8.56 6.10
22 16.20 7.37 4.84 15.71 7.46 5.23 14.94 7.39 5.69 13.91 7.17 6.21 13.29 7.11 6.58
17 13.72 12.21 4.21 13.19 12.01 4.54 12.45 11.58 4.94 11.58 11.11 5.37 10.95 10.84 5.69
27 19 14.88 11.01 4.50 14.31 10.88 4.85 13.50 10.53 5.28 12.56 10.17 5.74 11.88 9.86 6.08
22 16.19 8.90 4.86 15.64 8.92 5.24 14.82 8.75 5.70 13.77 8.40 6.20 13.16 8.29 6.57
17 13.69 13.41 4.19 13.20 13.06 4.53 12.42 12.42 4.88 11.67 11.67 5.24 11.09 11.09 5.46
29 19 14.85 12.62 4.48 14.31 12.45 4.84 13.51 12.02 5.22 12.65 11.58 5.60 12.03 11.30 5.84
22 16.12 10.56 4.93 15.57 10.51 5.33 14.73 10.23 5.75 13.79 9.93 6.17 13.15 9.73 6.43
17 13.67 13.39 4.17 13.20 13.20 4.52 11.55 11.55 4.84 11.73 11.73 5.16 11.18 11.18 5.31
32 19 14.82 14.68 4.46 14.31 14.31 4.83 13.51 13.51 5.18 12.72 12.72 5.51 12.12 12.12 5.68
22 16.08 13.18 4.97 15.53 13.04 5.40 14.71 12.65 5.78 13.80 12.28 6.15 13.15 11.97 6.34

Panasonic CS-F50DTE5 Specifications

General

Indoor unit type	Ceiling
Indoor unit weight	47000 g
Indoor units quantity	1
Indoor unit dimensions (WxDxH)	1600 x 700 x 250 mm
Indoor unit noise level (high speed)	50 dB
Outdoor unit weight	105000 g
Outdoor unit noise level	56 dB
Outdoor unit dimensions (WxDxH)	900 x 320 x 1340 mm
Hose length (max)	50 m
Inverter technology	Yes
Refrigerating medium	R410A
Cooling capacity (max)	47700 BTU/h
Heating capacity (max)	54600 BTU/h
Air conditioner functions	Cooling, Heating
Cooling capacity in watts (max)	14000 W
Heating capacity in watts (max)	16000 W
Cooling energy efficiency (EER, W/W)	2.91
Heating energy efficiency (COP, W/W)	3.41
