13.8. Operating characteristics
Main Power Compressor Motor Indoor Unit Outdoor Unit Electrical Data (50Hz)
Model Source Fan Motor Fan Motor
Voltage Frequency S.C. R.C. (A) IPT (kW) R.C. IPT R.C. IPT Current. (A) Power Con-
sumption (kW)
(V) (Hz) (A) COOL COOL (A) (kW) (A) (kW) COOL COOL
CS-F24DTE5 220 50 59 12.3 2.38 0.40 0.08 0.55 0.12 13.2 2.58
CU-J24DBE5 230 50 62 12.3 2.43 0.40 0.08 0.56 0.12 13.3 2.63
C 240 50 65 12.5 2.47 0.40 0.08 0.57 0.13 13.5 2.68
O CS-F24DTE5 380 50 23 3.60 2.38 0.40 0.08 0.55 0.12 4.55 2.58
O CU-J24DBE8 400 50 25 3.64 2.43 0.40 0.08 0.56 0.12 4.60 2.63
L 415 50 27 3.68 2.47 0.40 0.08 0.57 0.13 4.65 2.68
I CS-F28DTE5 220 50 62 11.9 2.59 0.45 0.09 0.57 0.12 12.9 2.80
N CU-J28DBE5 230 50 65 12.0 2.63 0.45 0.09 0.58 0.13 13.0 2.85
G 240 50 68 12.1 2.67 0.45 0.09 0.59 0.14 13.1 2.90
CS-F28DTE5 380 50 23 3.88 2.59 0.45 0.09 0.57 0.12 4.90 2.80
CU-J28DBE8 400 50 25 3.92 2.63 0.45 0.09 0.58 0.13 4.95 2.85
O 415 50 27 3.96 2.67 0.45 0.09 0.59 0.14 5.00 2.90
N CS-F34DTE5 220 50 92 17.49 3.79 0.35 0.08 0.46 0.10 18.30 3.97
L CU-J34DBE5 230 50 95 17.66 3.83 0.37 0.08 0.47 0.11 18.50 4.02
Y 240 50 98 17.84 3.87 0.38 0.09 0.48 0.11 18.70 4.07
CS-F34DTE5 220 50 41 5.73 3.66 0.35 0.08 0.46 0.10 6.00 3.84
CU-J34DBE8 230 50 44 5.82 3.70 0.37 0.08 0.47 0.11 6.10 3.89
M 240 50 47 5.91 3.74 0.38 0.09 0.48 0.11 6.20 3.94
O CS-F43DTE5 380 50 54 6.47 4.51 0.62 0.13 0.91 0.20 8.00 4.84
D CU-J43DBE8 400 50 57 6.63 4.54 0.63 0.14 0.94 0.21 8.20 4.89
E 415 50 60 6.78 4.56 0.65 0.15 0.97 0.23 8.40 4.94
L CS-F50DTE5 380 50 55 7.77 4.82 0.89 0.19 0.99 0.22 8.40 5.23
CU-J50DBE8 400 50 58 7.96 4.85 0.91 0.20 1.02 0.23 8.60 5.28
415 50 61 8.14 4.87 0.94 0.21 1.04 0.25 8.80 5.33
Legend: S.C.: Starting Current
R.C.: Running Current
IPT: Power Consumption
