48
2.Remove the air filters and then pull out the front grille form the unit body.
1. Separate the drain hose and the drain plate. 2. Loose fixing screw to remove the Human sensor
3. Pull out the discharge slightly.
Front grille
Removal Procedure for
Discharge Grille
