Net Weight lb (kg) 20 (9.0) 159 (72)
Compressor Type — Rotary (1 cylinder)
rolling piston type
Motor Type — Induction (2-poles)
Rated Output W — 500, 1,100
Air Circulation Type Cross-flow Fan Propeller Fan
Material AS + Glass Fiber 30% AES + Glass Fiber 12%
Motor Type Induction (4-poles) Induction (6-poles)
Input W 20.6 - 19.1, 28.7 - 27.1 65.8 × 2 - 50.5 × 2
Rated Output W (1 unit) 20 (2 units) 20 × 2
Fan Speed Low rpm 820 - 780, 890 - 835 —
Medium rpm 855 - 825, 1125 - 1075 —
High rpm 1040 - 1005, 1260 - 1235 —
SuperHigh rpm 1160 - 1140, 1340 - 1330 —
Heat Exchanger Description Evaporator Condenser
Tube material Copper Copper
Fin material Aluminium Aluminium
Fin Type Slit Fin Corrugated Fin
Row / Stage (Plate fin configuration, forced draft)
2×14,2×14 1 × 18, 2 × 19
FPI 18, 21 19, 16
Size (W × H × L) mm 614 × 294 × 25.4 856×457.2×22 706.2×482.6×44
669.9
Refrigerant Control Device — Capillary Tube
Refrigeration Oil (c.c) — SUNISO 4GDID or ATMOS M60
(290, 430)
Refrigerant (R-22) g (oz) — 860 - 1160, 30.3 - 40.9
Thermostat Electronic Control —
Protection Device — Overload Protector
Capillary Tube Length mm — Cooling;920,810, Heating;590,550
Flow Rate l/min — Cooling;4.0,7.0, Heating;8.2,12.5
Inner Diameter mm — Cooling;1.1,1.3, Heating;1.3,1.5
Air Filter Material
Style
(c.c) P.P.
Honeycomb
—
Capacity Control Capillary Tube
Compressor Capacitor µF, VAC — 15 µF, 440VAC, 30 µF, 440VAC
Fan Motor Capacitor µF, VAC 1.5 µF, 400VAC 1.2 µF, 400VAC, 1.2 µF, 400VAC
•
Specifications are subject to change without notice for further improvement.
7
CS-MA95KE CU-MA185KE / CS-MA125KE CU-MA245KE / CS-MA75KE / CS-MA125KE CU-MA195KE
