20 Replacement Parts List
(Note)
<Model: CU-MA185KE / CU-MA245KE>
NO. DESCRIPTION & NAME Q’TY CU-MA185KE CU-MA245KE REMARKS
1 CHASSY ASS’Y 1 CWD50K562A CWD50K626A
2 FAN MOTOR BRACKET 2 CWD54113 CWD54155
3 SCREW - FAN MOTOR BRACKET 8 CWH4580399
←
4 FAN MOTOR 2 CWA95245
←
0
5 SCREW - FAN MOTOR MOUNT 6 CWH55027
←
6 PROPELLER FAN 2 CWH00K052
←
7 NUT - PROPELLER FAN 2 CWH56032
←
8 COMPRESSOR 2 2PS164D3AD02 2KS224D5AC02 0
9 ANTI - VIBRATION BUSHING 6 CWH50077 CWH50055
10 NUT - COMPRESSOR MOUNT 6 CWH56000 CWH4582065
11 CONDENSER 2 CWB32C043 CWB32C225
12 HOLDER COUPLING ASS’Y 2 CWH35K017A CWH35K019A
13 3-WAY VALVE 2 CWB01343 CWB01379 0
14 2-WAY VALVE 2 CWB02224 CWB02269 0
15 4-WAY VALVE 2 CWB00002 CWB00003 0
16 TUBE ASS’Y (RECEIVER) 2 CWT01537 CWT01C240
17 STRAINER 2 CWB11025
←
18 TUBE ASS’Y (CHECK VALVE / CAPILLARY) 2 CWT01C257 CWT01C241
19 V - COIL COMPLETE 2 CWA43C424 CWA43C439 0
20 SOUND PROOF BOARD 2 CWH15C081 CWH15264
21 OVERLOAD PROTECTOR 2 CWA67C1210 CWA67C1212 0
22 TERMINAL COVER 2 CWH17038
←
23 HOLDER - O.L.P. 2 CWH34033
←
24 NUT - TERMINAL COVER 2 CWH7080300
←
25 SOUND PROOF MATERIAL 2 — CWG30779
26 SOUND PROOF MATERIAL 2 CWG30786 —
27 CONTROL BOARD 2 CWH10881 CWH10878
28 TERMINAL BOARD ASS’Y 2 CWA28C501 CWA28C502
29 CAPACITOR - COMPRESSOR 2 CWA31646 CWA31647 0
30 HOLDER CAPACITOR 2 CWH30057
←
31 CAPACITOR - FAN MOTOR (1.2µF, 400 V) 1, 1 CWA31341, CWA31342
←
0
32 ELECTROMAGNETIC SWITCH 4 CWA00059
←
0
33 TERMINAL BOARD ASS’Y 2 CWA4711012
←
34 ELECTROLYTIC CAPACITOR 2 CWA32C045
←
0
35 ELECTROLYTIC CAPACITOR 2 CWA32C067
←
0
36 TEMPERATURE RELAY 2 CWA14C1001
←
0
37 CABINET ASS’Y 2 CWE00K332A CWE00K251A
38 CABINET FRONT PLATE 1 CWE06C046E CWE06C104A
39 CONTROL BOARD COVER 2 CWH13302 CWH13C286
40 OPERATING INSTRUCTIONS 1 CWF563195
←
41 INSTALLATION INSTRUCTIONS 1 CWF612120 CWF612119
42 CHASSY ASSY’Y (LOWER) 1 CWD50K456D CWD50K612A
43 CABINET FRONT PLATE 1 CWE06C066A CWE06C108A
44 FLAT PLATE 1 CWD64188A CWD64189A
45 FLAT PLATE 1 CWD90964A CWD90955A
46 FLAT PLATE 1 CWD90962A CWD90964A
47 FLAT PLATE 1 CWD90973A CWD90977A
48 FLAT PLATE 1 CWD90961A CWD90959A
•
All parts are supplied from MAICO, Malaysia (Vendor Code: 061).
•
The above parts are kept for seven years in accordance with MEI service policy. However, longer lead time will be taken in
supplying the non-numbered parts.
•
“O” marked parts are recommended to be kept in stock.
89
CS-MA95KE CU-MA185KE / CS-MA125KE CU-MA245KE / CS-MA75KE / CS-MA125KE CU-MA195KE
