Panasonic CS-MA95KE - 16 Replacement Parts List; Parts List (Models 1)

(Note)
•
“O” marked parts are recommended to be kept in stock.
16 Replacement Parts List
<Model: CS-MA75KE / CS-MA95KE / CS-MA125KE>
NO. DESCRIPTION & NAME Q’TY CS-MA75KE CS-MA95KE CS-MA125KE REMARKS
1 CHASSY COMPLETE 1 CWD50C338
← ←
2 PARTICULAR PIECE 1 CWD931019
← ←
3 FAN MOTOR 1 CWA921033 CWA921032 CWA921031 0
4 LEAD WIRE - FAN MOTOR 1 CWA67C2097
← ←
5 CROSS FLOW FAN 1 CWH02C060
← ←
6 BEARING 1 CWH64K007
← ←
7 SCREW - CROSS FLOW FAN 1 CWH4580304
← ←
8 EVAPORATOR & TUBE ASS’Y COMPLETE 1 CWB30C1059
←
CWB30C1060
9 INTAKE AIR SENSOR HOLDER 1 CWH32142
← ←
10 ANTI VIBRATION BUSHING 1 CWH50211
← ←
11 FLARE NUT (1/4”) 1 CWH6002140
← ←
12 FLARE NUT (1/2”) OR (3/8”) 1 CWT25005 (3/8”)
←
CWT25007 (1/2”)
13 DISCHARGE GRILLE COMPLETE 1 CWE20C2062 CWE20C2061 CWE20C2085
14 VERTICAL VANE WITH TAB 2 CWE24458
← ←
15 VERTICAL VANE 10 CWE24457
← ←
16 CONNECTING BAR 2 CWE26194
← ←
17 AIR SWING MOTOR 1 CWA98260 CWA98C033
←
0
18 LEAD WIRE - AIR SWING MOTOR 1 CWA67C2106
← ←
19 CAP FOR DRAIN TRAY 1 CWH52C003
← ←
20 HORIZONTAL VANE 1 CWE241027
← ←
21 CONTROL BOARD 1 CWH10965 CWH10965
←
22 POWER SUPPLY CORD 1 CWA20C2102
← ←
23 ELECTRONIC CONTROLLER 1 CWA742320 CWA742327 CWA742313 0
24 RECEIVER 1 CWA74919
← ←
0
25 INDICATOR COMPLETE 1 CWE39C1024
← ←
0
26 LEAD WIRE - INDICATOR 1 CWA67C2105
← ←
27 TERMINAL BOARD 1 CWA28C2026
←
CWA28C2025 0
28 INDICATOR HOLDER 1 CWD931018
← ←
29 SENSOR COMPLETE 1 CWA50C608
← ←
0
30 CONTROL BOARD FRONT COVER 1 CWH13456
← ←
31 CONTROL BOARD TOP COVER 1 CWH13457
← ←
32 REMOTE CONTROL COMPLETE 1 CWA75C2081
← ←
0
33 FRONT GRILLE COMPLETE 1 CWE11C2106
← ←
34 INTAKE GRILLE COMPLETE 1 CWE22C1006
← ←
35 DECORATION BASE COMPLETE 1 CWE35C1007
← ←
36 TAB 2 CWD931020
← ←
37 AIR FILTER 2 CWD00240
← ←
38 GRILLE DOOR 1 CWE14236
← ←
39 SCREW FOR FRONT GRILLE 2 XTN4+16C
← ←
40 CAP FOR FRONT GRILLE 2 CWH52267
← ←
41 DRAIN HOSE 1 CWH5880580
← ←
44 INSTALLATION PLATE 1 CWH36157
← ←
45 BAG COMPLETE - INSTALLATION SCREW 1 CWH82C1054
← ←
46 AIR PURIFYING FILTER COMPLETE 1 CWD00C1028
← ←
47 AIR PURIFYING FILTER (CATECHIN) 2 CWD001014
← ←
0
48 AIR PURIFYING FILTER (DEODORIZING) 2 CWD001033
← ←
0
49 REMOTE CONTROL HOLDER 1 CWH36161
← ←
•
All parts are supplied from MACC, Malaysia (Vendor Code: 086).
