ENGLISH
7
Indoor unit preparation
1
If installed with the Catechin air purifying filter and Solar refreshing deodor-
izing filter (Accessories)
Lift up the front panel until it reaches a
horizontal position, then slowly remove
the filters by pulling outwards.
Grip a small part of the filter and pull
to remove.
The filter is slotted into the main unit
structure (via 6 plug-in points). (No
differentiation on inside or outside
surface.)
The filter is slotted into the main unit
structure (via 6 plug-in points). (No
differentiation on inside or outside
surface.)
● Any upward movement of the horizontally placed front panel
could detach the front panel. Please be careful of falling panel.
● Use them immediately after opening of packaging.
● Whichever side [right or left] you install the catechin filter and
the solar refreshing deodorizing filter, will not alter their effec-
tiveness.
NOTE:
2
POWER ON
Slot the filters along the guides and
push the sleeves in from the top to
lock.
To close the front panel.
● If there is a power failure, operation will be automatically restarted under the previous operation mode and
airflow direction when power is resumed. (When the operation is not stopped by remote control.)
● If you do not want the unit to restart automatically when power is resumed, switch off the main power supply.
● If you do not require Auto Restart Control, consult your dealer.
● Auto Restart Control is not available when Timer or Sleep mode is set or the dry mode timer is cancelled.
Auto Restart Control
Air filters (one each for right side
and left side)
Catechin air purifying filter
Solar
refreshing
deodorizing
filter
Air filters (one each for right side and
left side)
Press these 3 points to
close the front panel hatch.
Sleeves
To Next Page
