2 Specifications
2.1. CS-PC30EKF CU-PC30EKF
Unit Indoor unit Outdoor unit
Power Source (Phase, Voltage, Cycle) ø, V, Hz Single, 220 - 240, 50
Cooling Capacity kW (BTU/h) 8.79 (30,000)
Moisture Removal l/h (Pint/h) 5.2 (11.0)
Performance Test Condition JIS
Airflow Method OUTLET
INTAKE
SIDE VIEW
SIDE VIEW
Air Volume
Lo
m
3
/min (cfm)
16.9 (598) - 16.9 (598) —
Me
m
3
/min (cfm)
18.5 (654) - 18.5 (654) —
Hi
m
3
/min (cfm)
20.1 (710) - 20.1 (710) 51.0 (1,800) - 56.0 (1,980)
SHi
m
3
/min (cfm)
——
Noise Level dB (A) High 49 - 49, Low 44 - 44 High 53 - 54
Electrical Data Input Power W 3,050 - 3,150
Running Current A 14.2 - 13.8
EER W/W (BTU/hW) 2.88 - 2.79 (9.84 - 9.52)
Starting Current A 74.0
Piping Connection Port inch G ; Half Union 5/8” G : 3-way valve 5/8”
(Flare Piping) inch L ; Half Union 3/8” L ; 2-way valve 3/8”
Pipe Size inch G ; (Gas side) 5/8” G ; (Gas side) 5/8”
(Flare Piping) inch L ; (Liquid side) 3/8” L ; (Liquid side) 3/8”
Drain Inner diameter mm 14 —
Hose Length mm 660.5 —
Power Cord Length m — —
Number of core-wire — —
Dimensions Height inch (mm) 13 - 13/32 (340) 31 - 5/16 (795)
Width inch (mm) 15 - 9/32 (1,150) 35 - 7/16 (900)
Depth inch (mm) 10 - 1/4 (260) 12 - 5/8 (320)
Net Weight lb (kg) 40 (18) 154 (70)
Compressor Description — Rotary (1 cylinder)
rolling piston type
Motor Type — Induction (2-poles)
Rated Output W — 2,400
Air Circulation Description Cross-flow Fan Propeller Fan
Material ASG30K1 or ASG32K1 PP (MICA 30% + GF 10%)
Motor Type PWM (8-poles) Induction (6-poles)
Input W 66.0 148 - 177
Rated Output W 60 75
Fan Speed Low rpm 1,070 - 1,070 —
Medium rpm 1,170 - 1,170 —
High rpm 1,270 - 1,270 685 - 735
SuperHigh rpm — —
