<Model: CU-PC30EKF>
(Note)
• All parts are supplied from PHAAM, Malaysia (Vendor Code: 061).
• “O” marked parts are recommended to be kept in stock.
REF. NO. PART NAME & DESCRIPTION QTY. CU-PC30EKF REMARKS
1 BASE PAN ASS’Y 1 CWD52K1102
2 COMPRESSOR 1 2JD514D5AA03 O
3 ANTI - VIBRATION BUSHING 3 CWH50055
4 NUT FOR COMP. MOUNT. 3 CWH561049
5 PACKING 3 CWB811017
6 CONDENSER COMPLETE 1 CWB32C1778
7 OIL SEPARATER 1 CWB16000
8 TUBE ASS’Y (EXP. VALVE STRAINER) 1 CWT01C3691
9 TUBE ASS’Y (CAPILLARY TUBE) 1 CWT024153
10 3-WAYS VALVE (GAS) 1 CWB011429 O
11 STRAINER 1 CWB11061
12 3-WAYS VALVE (LIQUID) 1 CWB011294 O
13 SOUND PROOF BOARD 1 CWH151078
14 SOUND PROOF MATERIAL - COMP 1 CWG302372
15 V-COIL COMPLETE 1 CWA43C2128J
16 PIPE SENSOR (DISCHARGE) 1 CWA50C2292
17 PIPE SENSOR (COIL) 1 CWA50C2293
18 SPRING FOR SENSOR 2 CWH711010
19 CABINET REAR PLATE 1 CWE02C1033
20 CONTROL BOARD 1 CWH10K1078
21 MAGNETIC RELAY 1 K6C2A9A00001
22 TERMINAL BOARD ASS’Y 1 CWA28K1107
23 TERMINAL BOARD ASS’Y 1 CWA28K1076J
24 CAPACITOR - FM (3.0MF/460V) 1 DS461305QP-A O
25 CAPACITOR - COMP. (60MF/440V) 1 DS441606CPNA O
26 ELECTRONIC CONTROLLER - MAIN 1 CWA73C2132R O
27 TRANSFORMER 1 CWA401060
28 TERMINAL COVER 1 CWH171012
29 NUT FOR TERMINAL COVER 1 CWH7080300J
30 BRACKET - FAN MOTOR 1 CWD54K1027
31 SCREW - BRACKET FAN MOTOR 2 CWH551040J
32 FAN MOTOR 1 CWA951513 O
33 SCREW - FAN MOTOR 4 CWH551040J
34 PROPELLER FAN 1 CWH001019
35 NUT FOR PROPELLER FAN 1 CWH561038J
36 CABINET FRONT PLATE 1 CWE061118A
37 DISCHARGE GRILLE 1 CWE201073
38 CABINET SIDE PLATE ASS’Y 1 CWE04K1019A
39 WIRE NET 1 CWD041063A
40 CABINET TOP PLATE COMPLETE 1 CWE03C1032
41 PIPE COVER (FRONT) 1 CWD601074A
42 PIPE COVER (BACK) 1 CWD601081A
43 CABINET FRONT PLATE COMPLETE 1 CWE06C1131
44 HANDLE 3 CWE161008
45 WIRING COVER AND BAND 1 CWH82C1105
46 OPERATION INSTRUCTION 1 CWF565152
47 INSTALLATION INSTRUCTION 1 CWF612934
To Next Page
