Panasonic CS-PC9DKV - Page 11

Outdoor Unit
CU-PC9DKV
650
61.6
10cm
100cm
Required space for installation
<Front View>
<Side View>
<Top View>
Unit : mm
123.8
62.2
61.6
88 88
650
668
250
230
530
55.8
293
Air intake
Air outlet
CU-PC12DKV
10cm
11
CS-PC9DKV / CU-PC9DKV / CS-PC12DKV / CU-PC12DKV
