Unit CS-PE9CKE CU-PE9CKE
Air Circulation Type Cross-flow Fan Propeller fan
Motor Type Transistor(8poles) Induction (6 pole)
Input W — 56
Rated Output W 30 15
Fan Speed Low rpm 820±60 —
Medium rpm 1060±60 —
High rpm 1300±60 670±60
Heat Exchanger Description Evaporator Condenser
Tube Material copper copper
Fin Type slot type Corrugation type
Rows / Stage (Plate fin configuration, forced draft)
2×15 1×24
FPI 18 19
Dimensions mm 610 × 315 × 25.4 726 × 504 × 18.2
Refrigerant Control Device — Capillary Tube
Refrigeration Oil (c.c) — RB68A or Freol Alpha68A
Refrigerant (R410A) g — 840
Thermostat Electronic Control Overload Protector
Protection Device —
Capillary Length mm — 600
Circulation L/min — 8.15
Inner dia mm — 1.3
Air Filter P.P Honeycomb —
Refrigerant Circulation Control Device Capillary
Fan Motor Capacitor µFV — 1.2µF, 400V
•
• •
•
Specifications are subject to change without notice for further improvement
6
CS-PE9CKE / CU-PE9CKE / CS-PE12CKE / CU-PE12CKE
