3 Product Specifications
3.1. CS-PW18DKE CU-PW18DKE
Unit CS-PW18DKE CU-PW18DKE
Power Source (Phase, Voltage, Cycle) ø,V,Hz Single, 230, 50
Cooling Capacity kW (BTU/h) 5.10 (17,400)
Heating Capacity kW (BTU/h) 5.30 (18,100)
Moisture Removal l/h (Pint/h) 2.9 (6.1)
Airflow Method OUTLET
INTAKE
SIDE VIEW TOP VIEW
Air Volume Lo m
3
/min (cfm) Cooling; 13.1 (463)
Heating; 14.0 (494)
—
Me m
3
/min (cfm) Cooling; 15.1 (533)
Heating; 15.1 (533)
—
Hi m
3
/min (cfm) Cooling; 16.2 (570)
Heating; 16.4 (580)
29.0 (1,020)
SHi m
3
/min (cfm) — —
Noise Level dB (A) Cooling; High 45, Low 38
Heating; High 43, Low 38
Cooling; High 55
Heating; High 55
Power level dB Cooling; 58
Heating; 56
Cooling; 70
Heating; 70
Electrical Data Input Power kW Cooling; 1.75
Heating; 1.58
Running Current A Cooling; 7.7
Heating; 6.9
EER W/W (BTU/hW) Cooling; 2.91 (9.94)
COP W/W (BTU/hW) Heating; 3.35 (11.46)
Starting Current A 27.0
Piping Connection Port
(Flare piping)
inch
inch
G ; Half Union 1/2”
L ; Half Union 1/4”
G ; 3-way valve 1/2”
L ; 2-way valve 1/4”
Pipe Size
(Flare piping)
inch
inch
G ; (gas side) 1/2”
L ; (liquid side) 1/4”
G ; (gas side) 1/2”
L ; (liquid side) 1/4”
Drain
Hose
Inner diameter mm 16 —
Length mm 650 —
Power Cord Length m 1.9 —
Number of core-wire 3 (1.0 mm
2
) —
Dimensions Height inch (mm) 10 - 13/16 (275) 21 - 1/4 (540)
Width inch (mm) 39 - 9/32 (998) 30 - 23/32 (780)
Depth inch (mm) 9 - 1/16 (230) 11 - 3/8 (289)
Net Weight lb (kg) 24 (11.0) 99 (45.0)
Compressor Description — Rotary (1 cylinder)
rolling piston type
Motor Type — Induction (2-poles)
Rated Output kW — 1.5
Air Circulation Description Cross-flow Fan Propeller Fan
Material ASHT-18 PP
Motor Type Transistor (8-poles) Induction (6-poles)
Input W 39.6 74.1
Rated Output W 30 835
Fan Speed Low rpm Cooling; 1,190
Heating; 1,270
490
Medium rpm Cooling; 1,370
Heating; 1,370
—
High rpm Cooling; 1,470
Heating; 1,490
845
SuperHigh rpm — —
6
CS-PW18DKE CU-PW18DKE
