4. Location of Controls and Components
4.1 Indoor Unit
4.2 Outdoor Unit
4.3 Remote Control
z For normal operation, the ERROR RESET button is
not in use.
z Press RESET button to restore the remote control’s
default setting.
POWER GREEN
TIMER ORANGE
QUIET GREEN
INDICATOR
POWERFUL RED
OFF/ON
Operation
mode
Airflow direction
adjustment
Timer
setting
Temperature
setting
Transmitter
Fan speed
selection
Front Panel
A
ir Filter
Vertical airflow
direction louver
Horizontal airflow
direction louver
Receiver
