Panasonic CS-RE9JKX-1 User Manual

46
No. Parts Name
Q't
y
CS-RE9JKX-1 CS-RE12JKX-1 CS-RE15JKX-1 RE
1 CHASSIS COMPLETE 1 CWD50C1644 CWD50C1644 CWD50C1644
2 FAN MOTOR 1 ARW7629AC ARW7629AC ARW7629AC
3
CROSS FLOW FAN
COMPLETE
1 CWH02C1095 CWH02C1095 CWH02C1095
4 EVAPORATOR 1 CWB30C3215 CWB30C3274 CWB30C3275
5 AUXILIARY TUBE ASS'Y 1 CWT01C4858 CWT01C4858 CWT01C4844
6 DRAIN PLUG 1 CWH521096 CWH521096 CWH521096
7
DISCHARGE GRILLE
COMPLETE
1 CWE20C2970 CWE20C2970 CWE20C2970
8 AIR SWING MOTOR 1 CWA981161 CWA981161 CWA981161
9
HORIZONTAL AIR FLOW
VANE (L)
1 CWE24C1292 CWE24C1292 CWE24C1292
10
HORIZONTAL AIR FLOW
VANE (R)
1 CWE24C1291 CWE24C1291 CWE24C1291
11 VERTICAL AIR FLOW VANE 1 CWE241295 CWE241295 CWE241295
12 C-BOX 1 CWH14C7672 CWH14C7671 CWH14C7538
13 CONTROL BOARD CASING 1 CWH102377 CWH102377 CWH102377
14 PARTICULAR PIECE 1 CWD933089 CWD933089 CWD933089
15
TERMINAL BOARD
COMPLETE
1 CWA28C2383 CWA28C2383 CWA28C2442
16
POWER SUPPLY CORD
COMPLETE
1 CWA20C2862 CWA20C2862 CWA20C2894
17 MAIN PCB 1 CWA73C4038 CWA73C4037 CWA73C4036
18 SENSOR 1 CWA50C2596 CWA50C2596 CWA50C2596
19 INDICATOR HOLDER-FRONT 1 CWD933087 CWD933087 CWD933087
20 FIXING PIECE 1 CWD933088 CWD933088 CWD933088
21 INDICATOR PCB 1 CWA745415 CWA745415 CWA745415
22 INDICATOR LEAD WIRE 1 CWA67C8070 CWA67C8070 CWA67C8070
23
CONTROL BOARD TOP
COVER
1 CWH131359 CWH131359 CWH131359
24
CONTROL BOARD BACK
COVER
1 CWH131358 CWH131358 CWH131358
25 REMOTE CONTROL 1 CWA75C3077 CWA75C3077 CWA75C3077
26 FRONT GRILLE COMPLETE 1 CWE11C4267 CWE11C4267 CWE11C4267
27 INTAKE GRILLE 1 CWE22K1498 CWE22K1498 CWE22K1498
28 GRILLE DOOR 1 CWE14C1039 CWE14C1039 CWE14C1039
29 AIR FILTER 2 CWD001285 CWD001285 CWD001285
30 ALIRUBUSTER FILTER 1 CWD001202 CWD001202 CWD001202
31 SCREW-FRONT GRILLE 2 XTT4+16CFJ XTT4+16CFJ XTT4+16CFJ
32 CAP-FRONT GRILLE 2 CWH521196 CWH521196 CWH521196
33 DRAIN HOSE 1 CWH851136 CWH851136 CWH851136
34 OPERATING INSTRUTIONS 1 CWF567312 CWF567312 F567312
35
INSTALLATION
INSTRUCTION
1 CWF614336 CWF614336 F614336
36
INSTALLATION
INSTRUCTION
1 CWF614337 CWF614337 F614337
37 INSTALLATION PLATE 1 CWH361105 CWH361105 CWH361105
(Note)
• All parts are supplied from PHAAG, China
