Panasonic CS-RE9NKE Service Manual

5
2. Specification
Indoor CS-RE9NKE CS-RE12NKE
Model
Outdoor CU-RE9NKE CU-RE12NKE
Phase, Hz Single, 50 Single, 50
Power Supply
V 230 230
Min Rate Max Min Rate Max
kW 0.900 2.500 3.000 0.900 3.500 3.900
BTU/h 3070 8530 10230 3070 11940 13300
Capacity
kJ/h 770 2150 2580 770 3010 3350
Running Current A - 3.30 - - 4.70 -
Input Power W 190 700 1000 170 1010 1200
W/W 4.74 3.57 3.00 5.29 3.47 3.25
EER
BTU/hW 16.16 12.18 10.23 18.06 11.82 11.08
Power Factor % 92 93
dB-A (H / L / QLo)
Hi: 42 Lo: 27 QLo: 22 Hi: 42 Lo: 30 QLo: 22
Indoor Noise
Power Level 58 58
dB-A (H / L ) Hi: 47 Lo: - Hi: 48 Lo: -
COOLING
Outdoor Noise
Power Level 63 64
kW 0.900 3.300 4.100 0.900 4.250 5.100
BTU/h 3070 11250 13980 3070 14490 17390
Capacity
kJ/h 770 2840 3530 770 3660 4390
Running Current A - 3.80 - - 5.20 -
Input Power W 170 820 1150 150 1120 1460
W/W 5.29 4.02 3.57 6.00 3.79 3.49
COP
BTU/hW 18.06 13.71 12.16 20.47 12.94 11.91
Power Factor % 93 93
dB-A (H / L / QLo)
Hi: 42 Lo: 27 QLo: 25 Hi: 42 Lo: 33 QLo: 25
Indoor Noise
Power Level 58 58
dB-A (H / L ) Hi: 48 Lo: - Hi: 50 Lo: -
HEATING
Outdoor Noise
Power Level 64 66
Max Current (A) / Max Input Power (W) 6.30 / 1.350k 8.40 / 1.600k
Starting Current (A) 4.00 5.40
Type Hermetic Motor Hermetic Motor
Motor Type BRUSHLESS (6 poles) BRUSHLESS (6 poles)
Compressor
Output Power W 750 900
Type Cross-flow fan Cross-flow fan
Material AS(GF30%) AS(GF30%)
Motor Type DC (8 poles) DC (8 poles)
Input Power W - -
Output Power W 30 30
Q-Lo rpm 600 620
Lo rpm 700 790
Me rpm 920 970
Speed
(COOLING)
Hi rpm 1150 1150
Q-Lo rpm 650 680
Lo rpm 710 830
Me rpm 830 950
Indoor Fan
Speed
(HEATING)
Hi rpm 1040 1150
Type Propeller Propeller
Material PP(GF+PD)30% PP(GF+PD)30%
Motor Type DC (8 poles) DC (8 poles)
Input Power W - -
Output Power W 25 40
Cooling rpm 730 730
Outdoor Fan
Speed
Heating rpm 710 710
Moisture Removal L/h (Pt/h) 1.4 (2.4) 2.0 (3.5)
O-Lo m
3
/min (ft
3
/m) 6.51 (230) 6.74 (238)
Lo m
3
/min (ft
3
/m) 7.60 (268) 8.58 (303)
Me m
3
/min (ft
3
/m) 10.00(353) 10.54 (372)
Indoor Airflow
(COOLING)
Hi m
3
/min (ft
3
/m) 12.5 (441) 12.5(441)
Indoor Airflow O-Lo m
3
/min (ft
3
/m) 6.94 (245) 7.39 (261)
