Panasonic CS-RE9NKE Service Manual

6
Lo m
3
/min (ft
3
/m) 7.57 (267) 9.01 (318)
Me m
3
/min (ft
3
/m) 8.86 (313) 10.33 (364)
(HEATING)
Hi m
3
/min (ft
3
/m) 11.1 (392) 12.5 (441)
Hi (Cooling) m
3
/min (ft
3
/m) 31.4 (1108) 33.0 (1165)
Outdoor Airflow
Hi (Heating) m
3
/min (ft
3
/m) 31.4 (1108) 33.0 (1165)
Control Device Capillary Tube Capillary Tube
Refrigerant Oil cm
3
FV50S (250) FV50S (320)
Refrigeration
Cycle
Refrigerant Type g (oz) R410A, 640 (22.6) R410A, 780(27.5)
Height(I/D / O/D)
mm (inch) 290 (11-15/32)
530 (20-55/64)
290 (11-15/32)
540 (21-1/4)
Width (I/D / O/D)
mm (inch) 848 (33-13/32)
720(28-11/32)
848 (33-13/32)
780 (30-45/64)
Dimension
Depth (I/D / O/D)
mm (inch) 213(8-3/8) 275 (10-53/64)
213(8-3/8) 289 (11-3/8)
Weight Net (I/D / O/D) kg (lb) 8.0 (18) 20 (44) 8.0 (18) 26(57)
Pipe Diameter (Liquid /
Gas)
mm (inch) 6.35 (1/4) / 9.52 (3/8) 6.35 (1/4) / 9.52 (3/8)
Standard length m (ft) 5 (16.4) 5 (16.4)
Length range (min – max)
m (ft) 3 (9.8) ~ 15 (49.2) 3 (9.8) ~ 15 (49.2)
I/D & O/D Height different
m (ft) 5.0 (16.4) 5.0 (16.4)
Additional Gas Amount g/m (oz/ft) 20 (0.2) 20 (0.2)
Piping
Length for Additional Gas
m (ft) 7 (23.0) 7 (23.0)
Inner diameter mm 16 16 Drain Hose
Length mm 500 500
Fin Material Pre coated Pre coated
Fin Type Slit Fin Slit Fin
Row x Stage x FPI 2 x 15 x 19 2 x 15 x 19
Indoor
Heat
Exchanger
Size (W x H x L) mm 610 x 315 x 25.4 610 x 315 x 25.4
Fin Material Pre coated Pre coated
Fin Type Slit Fin Slit Fin
Row x Stage x FPI 1 x 24 x 19 2 x 24 x 17
Outdoor
Heat
Exchanger
Size (W x H x D) mm 661 x 504 x 18.19 703x 504 x 18.19
Material P.P.HONEY COMB P.P.HONEY COMB
Air Filter
Type One-touch One-touch
Power Supply Indoor Indoor
Power Supply Cord A 10A 10A
Thermostat - -
Protection Device - -
COOLING HEATING COOLING HEATING
TEMPERATURE (°C )
DB WB DB WB DB WB DB WB
Maximum 32 23 30 - 32 23 30 -
Indoor Operation Range
Minimum 16 11 16 - 16 11 16 -
Maximum 43 26 24 18 43 26 24 18
Outdoor Operation Range
Minimum 16 11 -5 -6 16 11 -5 -6
1. Cooling capacities are based on indoor temperature of 27°C Dry Bulb (80.6°F Dry Bulb), 19°C Wet Bu lb (66.2°F
Wet Bulb) and outdoor air temperature of 35°C Dry B ulb (95.0°F Dry Bulb), 24°C Wet Bulb (75.2°F Wet Bu lb).
2. Heating capacities are based on indoor temperature of 20°C Dry Bulb (68°F Dry Bulb) and outdoor ai r temperature
of 7°C Dry Bulb (44.6°F Dry Bulb), 6°C Wet Bulb (42 .8°F Wet Bulb).
3. Specifications are subjected to change without prior notice for further improvement.

Panasonic CS-RE9NKE Specifications

General

Brand	Panasonic
Model	CS-RE9NKE
Category	Air Conditioner
Language	English
