Panasonic CS-RE9NKE Service Manual

7
Indoor CS-RE15NKE
Model
Outdoor CU-RE15NKE
Phase, Hz Single, 50
Power Supply
V 230
Min Rate Max
kW 1.000 4.200 4.600
BTU/h 3410 14330 15700
Capacity
kJ/h 860 3610 3960
Running Current A - 6.00 -
Input Power W 210 1260 1650
W/W 4.76 3.33 2.78
EER
BTU/hW 16.23 11.37 9.51
Power Factor % 91
dB-A (H / L / QLo)
Hi: 46 Lo: 31 QLo: 29
Indoor Noise
Power Level 62
dB-A (H / L) Hi: 50 Lo: -
COOLING
Outdoor Noise
Power Level 66
kW 0.900 5.000 6.800
BTU/h 3070 17060 23200
Capacity
kJ/h 770 4300 5850
Running Current A - 6.30 -
Input Power W 210 1385 2280
W/W 4.28 3.61 2.98
COP
BTU/hW 14.61 12.31 10.17
Power Factor % 95
dB-A (H / L / QLo)
Hi: 46 Lo: 34 QLo: 28
Indoor Noise
Power Level 62
dB-A (H / L) Hi: 51 Lo: -
HEATING
Outdoor Noise
Power Level 67
Max Current (A) / Max Input Power (W) 10.5 / 2.280k
Starting Current (A) 6.40
Type Hermetic Motor
Motor Type BRUSHLESS (6 poles)
Compressor
Output Power W 700
Type Cross-flow fan
Material AS(GF30%)
Motor Type DC (8 poles)
Input Power W -
Output Power W 30
O-Lo rpm 730
Lo rpm 800
Me rpm 1040
Speed
(COOLIN
G)
Hi rpm 1320
O-Lo rpm 740
Lo rpm 900
Me rpm 1060
Indoor Fan
Speed
(HEATING
)
Hi rpm 1300
Type Propeller
Material PP
Motor Type DC (8 poles)
Input Power W -
Output Power W 40
Cooling rpm 750
Outdoor Fan
Speed
Heating Rpm 750
Moisture Removal L/h (Pt/h) 2.4 (4.2)
Q-Lo m
3
/min (ft
3
/m) 8.18 (289)
Lo m
3
/min (ft
3
/m) 8.97 (317)
Me m
3
/min (ft
3
/m) 11.65 (412)
Indoor Airflow
(COOLING)
Hi m
3
/min (ft
3
/m) 14.80 (523)
Q-Lo m
3
/min (ft
3
/m) 8.25 (291)
Lo m
3
/min (ft
3
/m) 10.03 (354)
Me m
3
/min (ft
3
/m) 11.82 (417)
Indoor Airflow
(HEATING)
Hi m
3
/min (ft
3
/m) 14.50 (512)
