8
Hi (COOLING) m
3
/min (ft
3
/m) 34.1 (1204)
Outdoor Airflow
Hi (HEATING) m
3
/min (ft
3
/m) 34.1 (1204)
Control Device Expansion valve
Refrigerant Oil cm
3
FV50S (320)
Refrigeration
Cycle
Refrigerant Type g (oz) R410A, 920 (32.4)
Height(I/D / O/D)
mm (inch) 290 (11-15/32) 540 (21-1/4)
Width (I/D / O/D)
mm (inch) 848(33-13/32) 780 (30-45/64)
Dimension
Depth (I/D / O/D)
mm (inch) 213 (8-3/8) 289(11-3/8)
Weight Net (I/D / O/D) kg (lb) 8.0 (18) 27(60)
Pipe Diameter (Liquid /
Gas)
mm (inch) 6.35 (1/4) / 12.7 (1/2)
Standard length m (ft) 5(16.4)
Length range (min – max)
m (ft) 3 (9.8) ~ 15 (49.2)
I/D & O/D Height different
m (ft) 5.0 (16.4)
Additional Gas Amount g/m (oz/ft) 20 (0.2)
Piping
Length for Additional Gas
m (ft) 7 (23.0)
Inner diameter mm 16 Drain Hose
Length mm 500
Fin Material Pre coated
Fin Type Slit Fin
Row x Stage x FPI 2 x 15 x 19
Indoor
Heat
Exchanger
Size (W x H x L) mm 610 x 315 x 25.4
Fin Material Pre coated
Fin Type Slit Fin
Row x Stage x FPI 2 x 24 x 17
Outdoor
Heat
Exchanger
Size (W x H x D) mm 703x 504 x 18.19
Material P.P.HONEY COMB
Air Filter
Type One-touch
Power Supply Indoor
Power Supply Cord A 16A
Thermostat -
Protection Device -
COOLING HEATING
TEMPERATURE (°C )
DRY BULB WET BULB DRY BULB WET BULB
Maximum 32 23 30 -
Indoor Operation Range
Minimum 16 11 16 -
Maximum 43 26 24 18
Outdoor Operation Range
Minimum 16 11 -5 -6
1. Cooling
capacities are based on indoor temperature of 27°C Dry Bulb (80.6°F Dry Bulb), 19°C Wet Bulb (66.2°F Wet
Bulb) and outdoor air temperature of 35°C Dry Bulb (95.0°F Dry Bulb), 24°C Wet Bulb (75.2°F Wet Bulb).
2. Heating capacities are based on indoor temperature of 20°C Dry Bulb (68°F Dry Bulb) and outdoor ai r temperature
of 7°C Dry Bulb (44.6°F Dry Bulb), 6°C Wet Bulb (42 .8°F Wet Bulb).
3. Specifications are subjected to change without prior notice for further improvement.
