Panasonic CS-RE9PKE-3 Service Manual

5
2. Specification
Indoor CS-RE9PKE-3 CS-RE12PKE-3
Model
Outdoor CU-RE9PKE-3 CU-RE12PKE-3
Phase, Hz Single, 50 Single, 50
Power Supply
V 230 230
Min Rate Max Min Rate Max
kW 0.90 2.50 3.00 0.90 3.50 3.90
BTU/h 3070 8530 10230 3070 11940 13300
Capacity
kcal/h 770 2150 2580 770 3010 3350
Running Current A - 3.30 - - 4.70 -
Input Power W 190 700 1000 170 1010 1200
W/W 4.74 3.57 3.00 5.29 3.47 3.25
BTU/hW 16.16 12.18 10.23 18.06 11.82 11.08
EER
kcal/hW 4.05 3.07 2.58 4.53 2.98 2.79
Pdesign C kW - 2.5 - - 3.5 -
SEER (W/W) - 5.6 - - 5.6 -
Annual
Consumption
kWh - 156 - - 219 -
Erp
Class - - A+ - - A+ -
Power Factor % 92 93
dB-A(H / L / QLo)
Hi: 42 Lo: 27 QLo: 22 Hi: 42 Lo: 30 QLo: 22
Indoor Noise
Power Level 58 58
dB-A (H / L ) Hi: 47 Lo: - Hi: 48 Lo: -
COOLING
Outdoor Noise
Power Level 63 64
kW 0.90 3.30 4.10 0.90 4.25 5.10
BTU/h 3070 11250 13980 3070 14490 17390
Capacity
kcal/h 770 2840 3530 770 3660 4390
Running Current A - 3.80 - - 5.20 -
Input Power W 170 820 1150 150 1120 1460
W/W 5.29 4.02 3.57 6.00 3.79 3.49
BTU/hW 18.06 13.71 12.16 20.47 12.94 11.91
COP
kcal/h/W 4.53 3.46 3.07 5.13 3.27 3.01
Pdesign H(A)
kW - 2.5 - - 3.2 -
Tbivalent
℃
- -10 - - -10 -
SCOP (W/W) - 3.4 - - 3.4 -
Annual
Consumption
kWh - 1029 - - 1318 -
Erp
Class - - A - - A -
Power Factor % 93 93
dB-A(H / L / QLo)
Hi: 42 Lo: 27 QLo: 25 Hi: 42 Lo: 33 QLo: 25
Indoor Noise
Power Level 58 58
dB-A (H / L ) Hi: 48 Lo: - Hi: 50 Lo: -
HEATING
Outdoor Noise
Power Level 64 66
Max Current (A) / Max Input Power (W) 6.30 / 1.350k 8.40 / 1.600k
Starting Current (A) 4.00 5.40
Standby Power (W) 7.5 7.5
Type Hermetic Motor compressor
Hermetic Motor compressor
Motor Type BRUSHLESS (6 poles) BRUSHLESS (6 poles)
Compressor
Output Power W 750 900
Type Cross-flow fan Cross-flow fan
Material AS(GF30%) AS(GF30%)
Motor Type DC (8 poles) DC (8 poles)
Input Power W 24.48 24.48
Output Power W 30 30
Q-Lo rpm 600 620
Lo rpm 700 790
Me rpm 920 970
Speed
(COOLING)
Hi rpm 1150 1150
Q-Lo rpm 650 680
Lo rpm 710 830
Me rpm 830 950
Indoor Fan
Speed
(HEATING)
Hi rpm 1040 1150

Panasonic CS-RE9PKE-3 Specifications

General

Indoor unit type	Wall-mountable
Indoor unit weight	8000 g
Indoor units quantity	1
Cooling airflow (indoor unit)	750 m³/h
Heating airflow (indoor unit)	666 m³/h
Indoor unit dimensions (WxDxH)	848 x 213 x 290 mm
Type	Air conditioner indoor unit
Ionizer	-
Remotely operated	Yes
Refrigerating medium	R410A
Cooling capacity (max)	- BTU/h
Dehumidifying capacity	1.4 l/h
Timer duration (maximum)	12 h
Air conditioner functions	Cooling, Dehumidifying, Heating
Cooling capacity in watts (max)	3000 W
Cooling capacity in watts (min)	900 W
Heating capacity in watts (max)	4100 W
Cooling energy efficiency (EER, W/W)	3.57
Heating energy efficiency (COP, W/W)	4.02
Seasonal efficiency rating (cooling) (SEER)	5.6
Seasonal efficiency rating (heating) (SCOP) (Average heating season)	3.4
Noise level (low speed)	22 dB
Noise level (high speed)	58 dB
Noise level (medium speed)	42 dB
Power requirements	230V, 16A
Annual energy consumption	156 kWh
