PART NAME & DESCRIPTION QTY. CU-TE20TKE CU-TE25TKE CU-TE35TKE REMARK
1 CHASSIS COMPLETE 1 ACXD52K00150 ← CWD52K1399
2 SOUND PROOF MATERIAL (TOP) 1 CWG302737 ← CWG302314
3 FAN MOTOR BRACKET 1 CWD541157 ← ←
4 SCREW - FAN MOTOR BRACKET 2 CWH551217 ← ←
5 FAN MOTOR 1 L6CAYYYL0064 ← L6CAYYYL0047 O
6 SCREW - FAN MOTOR MOUNT 4 CWH55252J ← ←
7 PROPELLER FAN ASSY 1 CWH03K1100 ← ←
8 NUT - PROPELLER FAN 1 CWH56053J ← ←
9 COMPRESSOR 1 5SS072XGA21 ← 5RS102XNA21 O
10 ANTI - VIBRATION BUSHING 3 CWH501038 ← CWH50077
11 NUT - COMPRESSOR MOUNT 3 CWH561096 ← ←
12 CONDENSER 1 ACXB32C00770 ACXB32C00780 CWB32C3797
13 EXPANSION VALVE 1 CWB051078 ← ←
14 DISCHARGE MUFFLER (4 W. VALVE) 1 CWB121010 ← ←
15 HOLDER COUPLING 1 CWH351233 ← ←
16 2-WAYS VALVE (LIQUID) 1 CWB021180J ← CWB021589 O
17 3-WAY VALVE (GAS) 1 CWB011374 ← ← O
19 REACTOR 1 G0C103J00045 ← G0C103J00013 O
20 TERMINAL COVER 1 CWH171041 ← CWH171039A
21 NUT - TERMINAL COVER 1 - - CWH7080300J
22 SOUND PROOF BOARD 1 CWH151427 ← ←
23 SOUND PROOF MATERIAL 1 ACXG30-00530 ← CWG302948
24 SENSOR CO - COMP TEMP 1 CWA50C2894 ← CWA50C2205 O
25 CONTROL BOARD COVER - TOP 1 CWH131264 ← ←
26 ELECTRONIC CONTROLLER - MAIN 1 ACXA73C22460R ACXA73C22740R ACXA73C21030R O
27 TERMINAL BOARD ASSY 1 CWA28K1110J ← ← O
28 CABINET SIDE PLATE CO. 1 ACXE04C00310 ← ←
29
SENSOR CO - AIR TEMP AND PIPE
TEMP
1 CWA50C3080 ← ← O
30 CABINET SIDE PLATE 1 ACXE04-00130A ← ←
31 CABINET FRONT PLATE CO. 1 CWE06C1566 ← ←
32 CABINET TOP PLATE 1 CWE031230A ← ←
33 PLATE - C. B. COVER TERMINAL 1 CWH131301 ← ←
34 CONTROL BOARD COVER CO. 1 CWH13C1359 ← ←
36 SOUND PROOF MATERIAL 1 - - CWG302316
38 4-WAYS VALVE 1 ACXB00-00130 ← ← O
39 V-COIL COMPLETE (4-WAY VALVE) 1 ACXA43C00250 ← ← O
41 BAG - COMPLETE 1 CWG87C900 ← ←
42 V-COIL COMPLETE (EXP. VALVE) 1 CWA43C2603 ← ← O
43 STRAINER 1 CWB11094 ← ←
44 DISCHARGE MUFFLER 1 CWB121021 ← ←
45 PLATE SPRING 1 CWH71044 ← -
46 PANASONIC BADGE 1 CWE373439 ← ←
52 INSTALLATION INSTRUCTION 1 ACXF60-07370 ← ←
53 INSTALLATION INSTRUCTION 1 ACXF60-07380 ← ←
54 INSTALLATION INSTRUCTION 1 ACXF60-07390 ← ←
55 INSTALLATION INSTRUCTION 1 ACXF60-07400 ← ←
56 INSTALLATION INSTRUCTION 1 ACXF60-07410 ← ←
