4. Location of Controls and Components
4.1 Indoor Unit
4.2 Outdoor Unit
4.3 Remote Control
Aluminium Fin
Auto OFF/ON button
• Use when remote control is misplaced
or malfunction occurs.
Air Filters
Front panel
Remote Control
receiver
Vertical Airflow
direction louver
• Do not adjust by hand.
Horizontal Airflow
direction louver
• Manually adjustable.
INDICATOR
(Green)
(Orange)
TIMER
POWER
A
ir Purifying Filter
Timer setting
Airflow direction
selection
Fan speed selection
Transmitter
Operation mode
Sleep mode operation
Powerful/Quiet
operation
Remote control
display
Clock setting
OFF/ON
Check
Temperature setting
