3 Product Specifications
Unit CS-V18CKE CU-V18CKE
Power Source Phase, Voltage, Cycle Single, 230, 50 Hz
Cooling Capacity kW (BTU/h) 5.30 (18,100)
Moisture Removal
l/h (Pint/h) 2.9 (6.1)
Airflow Method OUTLET
INTAKE
SIDE VIEW TOP VIEW
Air Volume Indoor Air (Lo) m
3
/min (cfm) 12.8 (450) 25.5 (900)
Indoor Air (Me) m
3
/min (cfm) 13.8 (490) —
Indoor Air (Hi) m
3
/min (cfm) 14.9 (530) 39.4 (1,390)
Indoor Air (SHi) m
3
/min (cfm) 15.5 (550) —
Noise Level dB (A) High 42, Low 37 High 55
Power level dB 54 70
Electrical Data Input Power kW 1.63
Running Current A 7.3
EER W/W (BTU/hW) 3.25 (11.10)
Starting Current A 27.0
Piping Connection Port
(Flare piping)
inch
inch
G ; Half Union 1/2”
L ; Half Union 1/4”
G ; 3-way valve 1/2”
L ; 2-way valve 1/4”
Pipe Size
(Flare piping)
inch
inch
G ; (gas side) 1/2”
L ; (liquid side) 1/4”
G ; (gas side) 1/2”
L ; (liquid side) 1/4”
Drain
Hose
Inner diameter mm 12 —
Length mm 650 —
Power Cord Length m 1.9 —
Number of core-wire 3 (1.5 mm
2
) —
Dimensions Height inch (mm) 10 - 13/16 (275) 26 - 31/32 (685)
Width inch (mm) 39 - 9/32 (998) 31 - 1/2 (800)
Depth inch (mm) 8 - 9/32 (210) 11 - 13/16 (300)
Net Weight lb (kg) 24 (11.0) 112 (51.0)
Compressor Type — Rotary (1 cylinder)
rolling piston type
Motor Type — Induction (2-poles)
Rated Output kW — 1.4
Air Circulation Type Cross-flow Fan Propeller Fan
Material ASHT-18 PP
Motor Type Transistor (8-poles) Induction (4-poles)
Input W 53.5 150
Rated Output W 30 67
Fan Speed Low rpm 1,130 660
Medium rpm 1,220 —
High rpm 1,320 1,020
SuperHigh rpm 1,370 —
6
CS-V18CKE CU-V18CKE / CS-V24CKE CU-V24CKE
