Unit CS-V24CKE CU-V24CKE
Power Source Phase, Voltage, Cycle Single, 230, 50 Hz
Cooling Capacity kW (BTU/h) 7.03 (24,000)
Moisture Removal l/h (Pint/h) 4.0 (8.5)
Airflow Method OUTLET
INTAKE
SIDE VIEW TOP VIEW
Air Volume Indoor Air (Lo) m
3
/min (cfm) 13.9 (490) 27.6 (980)
Indoor Air (Me) m
3
/min (cfm) 15.4 (540) —
Indoor Air (Hi) m
3
/min (cfm) 16.9 (600) 45.3 (1,600)
Indoor Air (SHi) m
3
/min (cfm) 17.5 (620) —
Noise Level dB (A) High 46, Low 40 High 60
Power level dB 59 74
Electrical Data Input Power kW 2.60
Running Current A 12.6
EER W/W (BTU/hW) 2.70 (9.23)
Starting Current A 65.0
Piping Connection Port
(Flare piping)
inch
inch
G ; Half Union 5/8”
L ; Half Union 1/4”
G ; 3-way valve 5/8”
L ; 2-way valve 1/4”
Pipe Size
(Flare piping)
inch
inch
G ; (gas side) 5/8”
L ; (liquid side) 1/4”
G ; (gas side) 5/8”
L ; (liquid side) 1/4”
Drain
Hose
Inner diameter mm 12 —
Length mm 650 —
Power Cord Length m 1.9 —
Number of core-wire 3 (2.5 mm
2
) —
Dimensions Height inch (mm) 10 - 13/16 (275) 26 - 31/32 (685)
Width inch (mm) 39 - 9/32 (998) 31 - 1/2 (800)
Depth inch (mm) 8 - 9/32 (210) 11 - 13/16 (300)
Net Weight lb (kg) 24 (11.0) 130 (59.0)
Compressor Type — Rotary (1 cylinder) rolling piston
type
Motor Type — Induction (2-poles)
Rated Output kW — 2.2
Air Circulation Type Cross-flow Fan Propeller Fan
Material ASHT-18 PC + AES + Glass Fiber 15%
Motor Type Transistor (8-poles) Induction (4-poles)
Input W 53.5 190.0
Rated Output W 30 108
Fan Speed Low rpm 1,220 720
Medium rpm 1,350 —
High rpm 1,480 1,180
SuperHigh rpm 1,530 —
8
CS-V18CKE CU-V18CKE / CS-V24CKE CU-V24CKE
