Note:
Unit CS-V24CKE CU-V24CKE
Heat Exchanger Description Evaporator Condenser
Tube material Copper Copper
Fin material Aluminium (Pre Coat) Aluminium (Blue Coat)
Fin Type Slit Fin Corrugated Fin
Row / Stage (Plate fin configuration, forced draft)
2×15 2×26
FPI 21 18
Size (W × H × L) mm 810 × 315 × 25.4 769.2
732.9
× 660.4 × 44.0
Refrigerant Control Device — Capillary Tube
Refrigeration Oil (cm
3
) — RB68A or FREOL ALPHA 68M
(1,130)
Refrigerant (R410A) g (oz) — 1,740 (61.4)
Thermostat Electronic Control Mechanical Control
Protection Device — Inner Protector
Capillary Tube Length mm — 611
Flow Rate l/min — 25.5
Inner Diameter mm — 2.1
Air Filter Material
Style
P.P.
Honeycomb
—
Capacity Control Capillary Tube
Compressor Capacitor µF, VAC — 45 µF, 370VAC
Fan Motor Capacitor µF, VAC — 3.5 µF, 450VAC
•
• •
•
Specifications are subject to change without notice for further improvement.
9
CS-V18CKE CU-V18CKE / CS-V24CKE CU-V24CKE
