Panasonic CS-W18CKE User Manual

18 Replacement Parts List
<Model: CU-W18CKE, CU-W24CKE>
REF. NO. PART NAME & DESCRIPTION QTY. CU-W18CKE CU-W24CKE REMARKS
1 CHASSY ASS’Y 1 CWD50K515B CWD50K514B
2 SOUND PROOF BOARD 1 CWH15223
←
←←
←
3 FAN MOTOR BRACKET 1 CWD54237
←
←←
←
4 SCREW - FAN MOTOR BRACKET 4 CWH55027
←
←←
←
5 FAN MOTOR 1 CWA921182 CWA921081 0
6 SCREW - FAN MOTOR MOUNT 4 CWH55252
←
←←
←
7 PROPELLER FAN ASS’Y 1 CWH00K087 CWH00K1001
8 NUT - PROPELLER FAN 1 CWH56053 CWH56060
9 COMPRESSOR 1 5KS205DAA 5JS315DAA 0
10 PACKING (3/2) CWB81043 (3) CWB81043 (2)
11 ANTI - VIBRATION BUSHING 3 CWH50055
←
←←
←
12 NUT - COMPRESSOR MOUNT 3 CWH4582065
←
←←
←
13 SOUND PROOF MATERIAL 1 CWG30894
←
←←
←
14 CONDENSER 1 CWB32C1298 CWB32C1300
15 HOLDER COUPLING ASS’Y 1 CWH35K029B CWH35K030B
16 2-WAY VALVE (LIQUID) 1 CWB021165
←
←←
←
0
17 3-WAY VALVE (GAS) 1 CWB011155 CWB011156 0
18 4-WAY VALVE ASS’Y 1 CWB00K1011 CWB00K1012 0
19 TUBE ASS’Y (CAPILLARY TUBE & STRAINER) 1 CWT01C2399 CWT01C2444
20 V-COIL COMPLETE 1 CWA43C2121
←
←←
←
0
21 TERMINAL COVER 1 CWH171012
←
←←
←
22 NUT - TERMINAL COVER 1 CWH7080300
←
←←
←
23 CONTROL BOARD 1 CWH10K1019
←
←←
←
24 CAPACITOR - FAN MOTOR (3.0MF/450V) 1 F0GAH305A002
←
←←
←
0
25 CAPACITOR - COMP 1 DS371506CPNA
(50MF/370VAC)
DS371456CPNA
(45MF/370VAC)
0
26 HOLDER CAPACITOR 1 CWH30060
←
←←
←
27 TERMINAL BOARD ASS’Y 1 CWA28K1021
←
←←
←
28 ELECTRONIC CONTROLLER (MAIN) 1 CWA743072
←
←←
←
30 SENSOR COMPLETE 1 CWA50C618
←
←←
←
31 HOLDER - SENSOR 1 CWH32089
←
←←
←
32 CABINET FRONT PLATE ASS’Y 1 CWE06K034B
←
←←
←
33 CABINET REAR PLATE 1 CWE02096B
←
←←
←
34 CABINET FRONT PLATE 1 CWE06075B
←
←←
←
35 CABINET SIDE PLATE 1 CWE04111B
←
←←
←
36 CABINET TOP PLATE 1 CWE03101B
←
←←
←
37 CONTROL BOARD COVER 1 CWH13336A
←
←←
←
38 HANDLE 2 CWE16000E
←
←←
←
39 OPERATION INSTRUCTIONS 1 CWF564067
←
←←
←
40 INSTALLATION INSTRUCTIONS 1 CWF612497
←
←←
←
41 INSTALLATION INSTRUCTIONS 1 CWF612498
←
←←
←
42 INSTALLATION INSTRUCTIONS 1 CWF612499
←
←←
←
43 SUPPORTER PLATE-COM 1 CWD90830
←
←←
←
44 L-TUBE 1 CWH5850080
←
←←
←
45 DRYER 1 CWB101002
←
←←
←
46 OPERATION INSTRUCTIONS 1 CWF564068
←
←←
←
47 OPERATION INSTRUCTIONS 1 CWF564069
←
←←
←
48 SOUND PROFF MATERIAL 1 CWG302107
←
←←
←
(Note)
•
• •
•
All parts are supplied from MAICO, Malaysia (Vendor Code: 061).
•
• •
•
“0” marked parts are recommended to be kept in stock.
77
CS-W18CKE CU-W18CKE / CS-W24CKE CU-W24CKE
