Panasonic CS-W18CKE User Manual

3 Product Specifications
Unit CS-W18CKE CU-W18CKE
Power Source Phase, Voltage, Cycle Single, 230, 50 Hz
Cooling Capacity kW (BTU/h) 5.30 (18,100)
Heating Capacity kW (BTU/h) 5.55 (18,900)
Moisture Removal l/h (Pint/h) 2.9 (6.1)
Airflow Method OUTLET
INTAKE
SIDE VIEW TOP VIEW
Air Volume Indoor Air (Lo) m
3
/min (cfm) Cooling; 13.3 (470)
Heating; 14.2 (500)
25.6 (904)
Indoor Air (Me) m
3
/min (cfm) Cooling; 14.8 (520)
Heating; 14.8 (520)
—
Indoor Air (Hi) m
3
/min (cfm) Cooling; 15.6 (550)
Heating; 16.4 (580)
40.0 (1,410)
Indoor Air (SHi) m
3
/min (cfm) Cooling; 16.4 (580)
Heating; 16.4 (580)
—
Noise Level dB (A) Cooling; High 43, Low 38
Heating; High 42, Low 38
Cooling; High 55
Heating; High 56
Power level dB Cooling; 55
Heating; 53
Cooling; 68
Heating; 69
Electrical Data Input Power kW Cooling; 1.65
Heating; 1.70
Running Current A Cooling; 7.4
Heating; 7.6
EER W/W (BTU/hW) Cooling; 3.21 (10.95)
COP W/W (BTU/hW) Heating; 3.26 (11.13)
Starting Current A 27.0
Piping Connection Port
(Flare piping)
inch
inch
G ; Half Union 1/2”
L ; Half Union 1/4”
G ; 3-way valve 1/2”
L ; 2-way valve 1/4”
Pipe Size
(Flare piping)
inch
inch
G ; (gas side) 1/2”
L ; (liquid side) 1/4”
G ; (gas side) 1/2”
L ; (liquid side) 1/4”
Drain
Hose
Inner diameter mm 12 —
Length mm 650 —
Power Cord Length m 1.9 —
Number of core-wire 3 (1.5 mm
2
) —
Dimensions Height inch (mm) 10 - 13/16 (275) 26 - 31/32 (685)
Width inch (mm) 39 - 9/32 (998) 31 - 1/2 (800)
Depth inch (mm) 8 - 9/32 (210) 11 - 13/16 (300)
Net Weight lb (kg) 24 (11.0) 121 (55.0)
Compressor Type — Rotary (1 cylinder)
rolling piston type
Motor Type — Induction (2-poles)
Rated Output kW — 1.4
6
CS-W18CKE CU-W18CKE / CS-W24CKE CU-W24CKE
