SAFETY
REF.
NO.
PART NAME & DESCRIPTION QTY. CU-Z20TKR CU-Z25TKR CU-Z35TKR REMARK
1 CHASSIS ASSY 1 CWD52K1399  
2
SOUND PROOF MATERIAL (COMP
TOP)
1 CWG302314  
3 FAN MOTOR BRACKET 1 CWD541157  
4 SCREW - FAN MOTOR BRACKET 2 CWH551217  
5 FAN MOTOR 1 L6CAYYYL0064   O
6 SCREW - FAN MOTOR MOUNT 4 CWH55252J  
7 PROPELLER FAN ASSY 1 CWH03K1100  
8 NUT - PROPELLER FAN 1 CWH56053J  
9 COMPRESSOR 1 9RS092XBB21 9RS102XFA21  O
10 ANTI - VIBRATION BUSHING 3 CWH50077  
11 NUT - COMPRESSOR MOUNT 3 CWH561096  
12 CONDENSER 1 CWB32C4289  
13
TUBE ASSY (CAP-TUBE, CHECK
VALVE & STRAINER)
1 ACXT00C00260 ACXB15C00050 ACXB15C00060
14 DISCHARGE MUFFLER 1 CWB121010  
15 HOLDER COUPLING 1 CWH351233  
16 2-WAYS VALVE (LIQUID) 1 CWB021589   O
17 3-WAY VALVE (GAS) 1 CWB011581   O
18 STRAINER 1 CWB111032  
19 REACTOR 1 G0C392J00028   O
20 TERMINAL COVER 1 CWH171039A  
21 NUT - TERMINAL COVER 1 CWH7080300J  
22 SOUND PROOF BOARD 1 CWH151428  
23
SOUND PROOF MATERIAL (700 mm x
290 mm)
1 CWG302948  
24 SENSOR CO-COMP TEMP 1 CWA50C2632   O
25 CONTROL BOARD COVER - TOP 1 ACXH13-00450  
26 ELECTRONIC CONTROLLER - MAIN 1 ACXA73C28850R ACXA73C28860R ACXA73C28870R O
27
TERMINAL BOARD ASSY (1, 2, 3, L, N,
A)
1 CWA28K1110J   O
28 CABINET SIDE PLATE CO. 1 CWE04C1587  
29
SENSOR CO-AIR TEMP AND PIPE
TEMP
1 CWA50C3267   O
30 CABINET SIDE PLATE (LEFT) 1 CWE041858A  
31 CABINET FRONT PLATE CO. 1 CWE06C1563  
32 CABINET TOP PLATE 1 CWE031230A  
33 PLATE - C. B. COVER TERMINAL 1 CWH131301  
34 CONTROL BOARD COVER CO. 1 CWH13C1359  
35 ELECTRONIC CONTROLLER - DM 1 ACXA73-00070   O
36
SOUND PROOF MATERIAL (520 mm x
300 mm)
1 CWG302316  
37 TERMINAL BOARD ASSY (DRM) 1 CWA28K1281   O
38 4-WAYS VALVE 1 CWB001063   O
39 V-COIL COMPLETE (4-WAYS VALVE) 1 CWA43C2431   O
40 WIRE NET 1 CWD041212A  
41 BAG-COMPLETE 1 CWG87C900  
42 FLEXIBLE PIPE (L-TUBE) 1 CWH5850080  
43 PACKING 1 CWB81012  
