201
SAFETY REF. NO. PART NAME & DESCRIPTION QTY. CU-Z42TKR CU-Z50TKR REMARK
1 CHASSIS COMPLETE 1 ACXD52K00320 ACXD52K01770
2 ANTI - VIBRATION BUSHING 3 CWH50077
3 COMPRESSOR 1 9RD132XAA21 O
4 NUT - COMPRESSOR MOUNT 3 CWH561096
5 SOUND PROOF MATERIAL (580 mm x 375 mm) 1 CWG302950
6 FAN MOTOR BRACKET 1 ACXD54-00140
7 FAN MOTOR 1 L6CAYYYL0076 O
8 SCREW - FAN MOTOR BRACKET 2 CWH551217
9 SCREW - FAN MOTOR MOUNT 3 CWH551106J
10 PROPELLER FAN ASSY 1 ACXH03K00070
11 NUT - PROPELLER FAN 1 CWH56053J
12 CONDENSER 1 ACXB32C09220 ACXB32C13850
14 EXPANSION VALVE 1 CWB051078
15 4-WAYS VALVE 1 ACXB00-00140 O
18 HOLDER COUPLING 1 ACXH35-00080 CWH351227
19 3-WAY VALVE (GAS) 1 ACXB01-00580 CWB011338 O
20 2-WAYS VALVE (LIQUID) 1 CWB021654 CWB021454 O
22 SOUND PROOF BOARD 1 ACXH15-00200 ACXH15-00230
23 TERMINAL COVER 1 CWH171039A
24 NUT - TERMINAL COVER 1 CWH7080300J
25 SENSOR CO - COMP TEMP 1 CWA50C2185 O
27 V-COIL COMPLETE (4-WAY VALVE) 1 ACXA43C00250 O
28 V-COIL COMPLETE (EXP. VALVE) 1 CWA43C2603 O
30 SENSOR - COMPLETE (AIR & PIPE TEMP) 1 CWA50C3079
31 REACTOR 1 G0C392J00029 O
33 TERMINAL BOARD ASSY (L, N, 1, 2, 3) 1 CWA28K1110J O
35 ELECTRONIC CONTROLLER - DM 1 ACXA73-00070
37 TERMINAL BOARD ASSY (DRM) 1 CWA28K1281
38 ELECTRONIC CONTROLLER - MAIN 1 ACXA73C28880R ACXA73C28890R O
40 CONTROL BOARD COVER - TOP 1 ACXH13-00490
41 CABINET SIDE PLATE (LEFT) 1 ACXE04-00490A
42 HANDLE 1 CWE161010
43 CABINET SIDE PLATE (RIGHT) 1 ACXE04C00690 ACXE04C00620
45 CABINET FRONT PLATE CO. 1 ACXE06K00050
46 WIRE NET 1 ACXD04-00130A
47 CABINET TOP PLATE 1 ACXE03-00170A
48 CONTROL BOARD COVER - COMPLETE 1 ACXH13C00170
49 CONTROL BOARD COVER 1 CWH131470
51 TUBE ASS'Y (CAPPILARY TUBE) 1 - ACXT00C20450
52 DISCHARGE MUFFLER 1 CWB121010 -
54 PANASONIC BADGE 1 CWE373439
55 INVERTER BADGE 1 CWE373441
58 SOUND PROOF MATERIAL (500 mm x 375 mm) 1 CWG302636
59 SOUND PROOF MATERIAL (COMP TOP) 1 CWG302630
62 RECEIVER 1 CWB14011
66 SOUND PROOF MATERIAL (340 mm x 160 mm) 1 ACXG30-00200 -
67 STRAINER 1 CWB111032
To Next Page
