203
SAFETY REF. NO. PART NAME & DESCRIPTION QTY. CU-Z60TKR CU-Z71TKR REMARK
1 CHASSIS COMPLETE 1 ACXD52K00280
2 ANTI - VIBRATION BUSHING 3 CWH50055
3 COMPRESSOR 1 9KD240XBA21 O
4 NUT - COMPRESSOR MOUNT 3 CWH561049
5 SOUND PROOF MATERIAL (660 mm x 335 mm) 1 CWG302997
6 FAN MOTOR BRACKET 1 ACXD54-00140
7 FAN MOTOR 1 L6CAYYYL0076 O
8 SCREW - FAN MOTOR BRACKET 2 CWH551217
9 SCREW - FAN MOTOR MOUNT 3 CWH551106J
10 PROPELLER FAN ASSY 1 ACXH03K00070
11 NUT - PROPELLER FAN 1 CWH56053J
12 CONDENSER 1 ACXB32C13850
14 EXPANSION VALVE 1 CWB051079
15 4-WAYS VALVE 1 ACXB00-00140 O
18 HOLDER COUPLING 1 ACXH35-00080
19 3-WAY VALVE (GAS) 1 CWB011363 O
20 2-WAYS VALVE (LIQUID) 1 ACXB02-00220 O
22 SOUND PROOF BOARD 1 ACXH15-00230
23 TERMINAL COVER 1 CWH171039A
24 NUT - TERMINAL COVER 1 CWH7080300J
25 SENSOR CO - COMP TEMP 1 CWA50C2185 O
27 V-COIL COMPLETE (4-WAY VALVE) 1 ACXA43C00250 O
28 V-COIL COMPLETE (EXP. VALVE) 1 CWA43C2603 O
30 SENSOR - COMPLETE (AIR & PIPE TEMP) 1 CWA50C3079
31 REACTOR 1 G0C392J00029 O
33 TERMINAL BOARD ASSY (L, N, 1, 2, 3) 1 CWA28K1110J O
35 ELECTRONIC CONTROLLER - DM 1 ACXA73-00070
37 TERMINAL BOARD ASSY (DRM) 1 CWA28K1281
38 ELECTRONIC CONTROLLER - MAIN 1 ACXA73C28900R ACXA73C28840R O
40 CONTROL BOARD COVER - TOP 1 ACXH13-00490
41 CABINET SIDE PLATE (LEFT) 1 ACXE04-00490A
42 HANDLE 1 CWE161010
43 CABINET SIDE PLATE (RIGHT) 1 ACXE04C00620
45 CABINET FRONT PLATE CO. 1 ACXE06K00050
46 WIRE NET 1 ACXD04-00130A
47 CABINET TOP PLATE 1 ACXE03-00170A
48 CONTROL BOARD COVER - COMPLETE 1 ACXH13C00170
49 CONTROL BOARD COVER 1 CWH131470
50 PACKING 3 CWB81043
51 TUBE ASS'Y (CAPPILARY TUBE) 1 ACXT00C20450
52 RECEIVER 1 CWB14030
53 ACCUMLATOR 1 ACXB13-00010
54 PANASONIC BADGE 1 CWE373439
55 INVERTER BADGE 1 CWE373441
58 SOUND PROOF MATERIAL (500 mm x 375 mm) 1 CWG302636
59 SOUND PROOF MATERIAL (COMP TOP) 1 CWG302246
62 DISCHARGE MUFFLER 1 CWB121013
67 STRAINER 1 CWB111032
