206
SAFETY REF. NO. PART NAME & DESCRIPTION QTY. CU-Z80TKR REMARK
1 CHASSIS ASSY 1 CWD52K1190
2 ANTI - VIBRATION BUSHING 3 CWH50055
3 PACKING 3 CWB81043
4 COMPRESSOR 1 9KD240XBA21 O
5 NUT - COMPRESSOR MOUNT 3 CWH561049
6 SOUND PROOF MATERIAL (COMP TOP) 1 CWG302246
7 SOUND PROOF MATERIAL (660 mm x 345 mm) 1 CWG302951
9 FAN MOTOR BRACKET 1 CWD541127
10 FAN MOTOR 1 EHDS80C60AC O
11 SCREW - FAN MOTOR BRACKET 2 CWH551217
12 SCREW - FAN MOTOR MOUNT 4 CWH551323
13 PROPELLER FAN ASSY 1 CWH00K1006
14 NUT - PROPELLER FAN 1 CWH561092
15 CONDENSER 1 CWB32C3295
16 TUBE ASSY CO. (CAP TUBE) 1 CWT01C5849
17 DISCHARGE MUFFLER (4 WAY VALVE) 1 CWB121013
18 EXPANSION VALVE 1 CWB051079
19 RECEIVER 1 CWB14017
20 STRAINER 2 CWB111063
22 4-WAYS VALVE 1 CWB001026J
24 HOLDER COUPLING 1 CWH351228
25 3-WAY VALVE (GAS) 1 CWB011363 O
26 2-WAYS VALVE (LIQUID) 1 CWB021464 O
27 SOUND PROOF BOARD 1 CWH151197
28 TERMINAL COVER 1 CWH171039A
29 NUT - TERMINAL COVER 1 CWH7080300J
32 V-COIL COMPLETE (4 WAY VALVE) 1 CWA43C2169J O
33 V-COIL COMPLETE (EXP. VALVE) 1 CWA43C2603
34 SENSOR CO - COMP TEMP 1 CWA50C2185 O
35 SENSOR CO - AIR TEMP AND PIPE TEMP 1 CWA50C2517 O
36 REACTOR 1 G0C452J00002 O
37 TERMINAL BOARD ASSY (DRM) 1 CWA28K1281
38 TERMINAL BOARD ASSY (1, 2, 3) 1 CWA28K1076J
39 TERMINAL BOARD ASSY (L, N) 1 CWA28K1162
40 ELECTRONIC CONTROLLER - MAIN 1 ACXA73C28760R O
41 CONTROL BOARD COVER - TOP 1 CWH131333
42 ELECTRONIC CONTROLLER - NF 1 ACXA73-19010 O
43 HANDLE 1 CWE161010
44 CABINET SIDE PLATE CO. 1 CWE041319A
45 CABINET SIDE PLATE 1 CWE041317A
46 CABINET FRONT PLATE CO. 1 CWE06K1063
48 CABINET TOP PLATE 1 CWE031083A
49 CONTROL BOARD COVER CO. 1 CWH13C1185
50 WIRE NET 1 CWD041128A
51 ACCESSORY CO. (DRAIN ELBOW) 1 CWG87C900
52 FLEXIBLE PIPE (L-TUBE) 1 CWH5850080
53 PACKING - L.TUBE 1 CWB81012
54 PANASONIC BADGE 1 CWE373439
54A INVERTER BADGE 1 CWE373441
