Panasonic CS-Z25UD3RAW Service Manual

27
6. Dimensions
6.1 Indoor Unit
(AIR OUTLET DUCT FLANGE)
692
145
(AIR OUTLET DUCT FLANGE)
96
27
160 × 4 = 640
5 - Ø 3.1 HOLE
26
750
824
904
640
564
194
AIR FILTER
(AIR INLET)
126
680
(AIR INLET)
23132220220132
14
14
23 155
120
23
40
23
200
150
DRAIN PORT
(UPPER & LOWER)
120
33
80 143
44 238
81
WATER
INLET
28
84
30
10
2 - Ø 3.1 HOLE
<Remote control transmitter>
<Remote Control>
<Top View>
<Side View>
<Side View>
<Front View>
<Back View>
15.5
Panasonic
116
120
Unit: mm

Panasonic CS-Z25UD3RAW Specifications

General

Cooling Capacity	2.5 kW
Refrigerant	R32
Power Supply	220-240V, 50Hz
Outdoor Unit Dimensions (W x H x D)	780 x 540 x 285 mm
Energy Efficiency Class (Cooling)	A++
