Panasonic CS-Z25XKEW Service Manual

7
CAUTION
9.
Installation or servicing work.
It may need two people to carry out the installation or servicing work.
10. Keep any required ventilation openings clear of obstruction.
11.
Pb free solder has a higher melting point than standard solder; typically the melting point is 50°F – 70°F (30°C – 40°C) higher.
Please use a high temperature solder iron. In case of the soldering iron with temperature control, please set it to 700 ± 20°F (370 ± 10°C).
Pb free solder will tend to splash when heated too high (about 1100°F / 600°C).
12.
Do not touch the sharp aluminum fins or edges of metal parts.
If you are required to handle sharp parts during installation or servicing, please wear hand glove.
Sharp parts may cause injury.
13.
Tighten the flare nut with torque wrench according to specified method. If the flare nut is over-tightened, after a long period, the flare may
break and cause refrigerant gas leakage.
14. Do not touch outdoor unit air inlet and aluminium fin. It may cause injury.

Panasonic CS-Z25XKEW Specifications

General

Type	Air conditioner indoor unit
Timer	Yes
Multi-split	-
Product color	White
Gas hose diameter	9.52 mm
Hose length (max)	15 m
Liquid hose diameter	6.35 mm
Dehumidifying capacity	1.5 l/h
Air conditioner functions	Cooling, Heating
Cooling capacity in watts (max)	3500 W
Cooling capacity in watts (min)	850 W
Heating capacity in watts (max)	3890 W
Heating capacity in watts (min)	5000 W
Cooling capacity in watts (nominal)	2500 W
Seasonal efficiency rating (cooling) (SEER)	9.4
Heating capacity in watts (nominal) (Warmer heating season)	- W
Heating capacity in watts (nominal) (Average heating season)	4900 W
Seasonal efficiency rating (heating) (SCOP) (Average heating season)	5.2
Design load (cooling)	- kW
Energy efficiency scale	A+++ to D
Energy efficiency class (cooling)	A+++
Annual energy consumption (cooling)	93 kWh
Hourly energy consumption (cooling)	- kWh
Annual energy consumption (heating) (Average heating season)	646 kWh
Indoor unit type	Wall-mountable
Indoor unit depth	229 mm
Indoor unit width	870 mm
Indoor unit height	295 mm
Indoor unit weight	10000 g
Indoor units quantity	1
Cooling airflow (indoor unit)	720 m³/h
Heating airflow (indoor unit)	840 m³/h
Indoor unit sound power level	57 dB
Indoor unit noise level (low speed)	25 dB
Indoor unit noise level (high speed)	39 dB
Outdoor unit noise level	- dB
