Parts List
REPLACEMENT PARTS LIST
Models: CT-27D10B, CT-27D10UB & CT-27D10DB
Important Safety Notice: Components printed in BOLD TYPE have special characteristics important
for safety. When replacing any of these components use only manufacturer’s specified parts.
074-00
PARTS LIST
C3019 ECA1CM100 CAP,E 10UF/16V
C3020 ECA1HM010 CAP,E 1.0UF/50V
C3021 ECJ2VF1H103Z CAP,C .01UF-Z-50V
C3022 ECA1HM010 CAP,E 1.0UF/50V
C3023 ECA1CM100 CAP,E 10UF/16V
C6501 ECA0JM101 CAP,E 100UF/6.3V
C6502 ECJ2VF1H103Z CAP,C .01UF-Z-50V
C6504 ECJ2VC1H270J CAP,C 27PF-J-50V
C6507 ECJ2VC1H120J CAP,C 12PF-J-50V
C6510 ECJ2VC1H120J CAP,C 12PF-J-50V
C6511 ECA1HM010 CAP,E 1.0UF/50V
C6512 ECJ2VF1H103Z CAP,C .01UF-Z-50V
C6513 ECJ2VC1H270J CAP,C 27PF-J-50V
C6516 ECJ2VF1H103Z CAP,C .01UF-Z-50V
C6517 ECEA1HN010U CAP,E 1UF/50V
C6518 ECJ2VF1H103Z CAP,C .01UF-Z-50V
C6520 ECA1CM100 CAP,E 10UF/16V
C6521 ECA1AM470 CAP,E 47UF/10V
C6522 ECJ2VC1H221J CAP,C 220PF-J-50V
C6523 ECJ2VF1H104Z CAP,C .1UF-Z-50V
C6524 ECA1HM010 CAP,E 1.0UF/50V
C6525 ECJ2VF1H103Z CAP,C .01UF-Z-50V
C6526 ECA1HM3R3 CAP,E 3.3UF/50V
C6527 ECJ2VF1H104Z CAP,C .1UF-Z-50V
C6528 ECA1AM470 CAP,E 47UF/10V
C6529 ECA1CM100 CAP,E 10UF/16V
C6531 ECJ2VF1H103Z CAP,C .01UF-Z-50V
C6532 ECJ2VF1H103Z CAP,C .01UF-Z-50V
DIODES
D001 ERA15-01 DIODE
D002 MA165 DIODE
D003 MA4056M DIODE
D006 MA4330H DIODE
D007 ERA15-01 DIODE
D008 ERA15-01 DIODE
D009 ERA15-01 DIODE
D011 MA165 DIODE
D014 MA165 DIODE
D015 MA165 DIODE
D018 MA165 DIODE
D451 ERA15-01 DIODE
D502 MA4062L DIODE
D530 MA4082L DIODE
D531 AS01 DIODE
D532 MA4091M DIODE, ZENER
D551 TVSRU2N DIODE
D554 BYD33G-163 DIODE
D555 MA165 DIODE
D556 MA4360H DIODE, ZENER
REF NO. PART NO. DESCRIPTION
D557 TVSRU2N DIODE
D558 RS3FS DIODE
D559 BYD33G-113 DIODE
D561 BYD33G-163 DIODE
D801 GP15KL-042 DIODE
D802 GP15KL-042 DIODE
D805 TRPW5B0M050D THERMISTOR
D806 MA4047M DIODE, ZENER
D807 MA165 DIODE
D809 RU3YX-M DIODE
D820 EU02V1 DIODE
D821 EU02V1 DIODE
D822 EU02V1 DIODE
D823 RL30A DIODE
D824 EU02V1 DIODE
D825 TVSSR2KL DIODE, PROTECTION
D826 EU02V1 DIODE
D829 MA165 DIODE
D830 MA4270M DIODE
D2301 MA165 DIODE
D2305 MA4110M DIODE, ZENER
D2306 MA4110M DIODE, ZENER
D2307 MA4110M DIODE, ZENER
D2308 MA4110M DIODE, ZENER
D2315 MA165 DIODE
D2342 MA165 DIODE
D2343 MA165 DIODE
D3001 MA4110M DIODE, ZENER
D3002 MA4110M DIODE, ZENER
D3003 MA4110M DIODE, ZENER
D3004 MA4110M DIODE, ZENER
D3005 MA4110M DIODE, ZENER
D3006 MA4110M DIODE, ZENER
D3007 MA4110M DIODE, ZENER
D3008 MA4110M DIODE, ZENER
D3009 MA4110M DIODE, ZENER
D3010 MA4110M DIODE, ZENER
D3015 MA4110M DIODE, ZENER
D3016 MA4110M DIODE, ZENER
D3017 MA4110M DIODE, ZENER
D3018 MA4110M DIODE, ZENER
D3019 MA4110M DIODE, ZENER
D3020 MA4110M DIODE, ZENER
D3021 MA4110M DIODE, ZENER
D3022 MA4110M DIODE, ZENER
D6501 MA165 DIODE
FUSES
F801 XBA2A00101 FUSE 6.3A 125V
F801-1 TP00351-51 FUSE CLIP
