REPLACEMENT PARTS LIST
Models: CT-27D10B, CT-27D10UB & CT-27D10DB
Important Safety Notice: Components printed in BOLD TYPE have special characteristics important
for safety. When replacing any of these components use only manufacturer’s specified parts.
- 39 -
074-00
PARTS LIST
Parts List
F801-2 TP00351-51 FUSE CLIP
INTEGRATED CIRCUITS
IC001 MN101C46FTA INT CKT
IC002 24LC08BIP INT CKT
IC003 PIC-26042SR INT CKT
IC005 PQ1R33 INT CKT
IC006 PST9229NR INT CKT
IC101 TA1310BN INT CKT
IC451 LA7845N INT CKT
IC551 AN78M09 PLUS 9V AVR
IC552 AN7805 INT CKT
IC801 PC817X2 INT CKT
IC803 STR58041A INT CKT
IC2201 AN5849S-E1V INT CKT
IC2302 AN5272 INT CKT
IC2351 CXA2021S INT CKT
IC3001 M52790SP INT CKT A/V SWITCH
IC6501 MN82840 INT CKT
COILS
L001 EXCELSA35 FERRITE BEAD
L003 TLTABT2R2K COIL, PEAKING 2.2UH
L004 TLTABT2R2K COIL, PEAKING 2.2UH
L005 ELESN330KA COIL, PEAKING 33UH
L006 EXCELSA24T FERRITE BEAD
L008 TLTABT470K COIL, PEAKING 47UH
L010 TLTABT2R2K COIL, PEAKING 2.2UH
L011 TLTABT2R2K COIL, PEAKING 2.2UH
L012 TLTABT2R2K COIL, PEAKING 2.2UH
L013 TLTABT2R2K COIL, PEAKING 2.2UH
L106 EXCELSA35T FERRITE BEAD
L218 EXCELSA35T FERRITE BEAD
L351 TLTABT101K COIL, PEAKING
L501 ELESN3R3KA COIL, PEAKING 3.3UH
L518 TLTABT120K COIL, PEAKING 12UH
L541 EXCELDR35 FERRITE BEAD
L551 ELH5L7103 COIL
L554 EXCELSA24T FERRITE BEAD
L555 EXCELSA24T FERRITE BEAD
L556 EXCELSA24T FERRITE BEAD
L801 ELF20N020A COIL, 2UH
L803 ELF17N007A LINE FILTER
L804 EXCELSA39 FERRITE BEAD
L2310 TLTABT2R2K COIL, PEAKING 2.2UH
L6502 ELESN330JA COIL, PEAKING 33UH
L6505 ELESN330JA COIL, PEAKING 33UH
L6507 ELESN150KA COIL, PEAKING 15UH
L6508 EXCELSA35T FERRITE BEAD
TRANSISTORS
Q001 2SD601ARTX TRANSISTOR
Q002 2SC1685QRS TRANSISTOR
REF NO. PART NO. DESCRIPTION
Q003 2SD601ARTX TRANSISTOR
Q004 2SC1685QRS TRANSISTOR
Q005 2SD601ARTX TRANSISTOR
Q201 2SD601ARTX TRANSISTOR
Q302 2SD601ARTX TRANSISTOR
Q303 2SD601ARTX TRANSISTOR
Q351 2SC3063 TRANSISTOR
Q352 2SC3063 TRANSISTOR
Q353 2SC3063 TRANSISTOR
Q401 2SD601ARTX TRANSISTOR
Q402 2SD601ARTX TRANSISTOR
Q501 2SC4212H TRANSISTOR
Q509 2SD601ARTX TRANSISTOR
Q515 2SD601ARTX TRANSISTOR
Q551 2SD2539MA1 TRANSISTOR
Q603 2SD601ARTX TRANSISTOR
Q801 2SC1685RSTA TRANSISTOR
Q802 2SC1384RS TRANSISTOR
Q2302 2SB709ARTX TRANSISTOR
Q2303 2SD601ARTX TRANSISTOR
Q2342 2SB709ARTX TRANSISTOR
Q2343 2SD601ARTX TRANSISTOR
Q2409 2SD601ARTX TRANSISTOR
Q2410 2SD601ARTX TRANSISTOR
Q6501 2SD601ARTX TRANSISTOR
Q6502 2SD601ARTX TRANSISTOR
Q6504 2SD601ARTX TRANSISTOR
Q6505 2SD601ARTX TRANSISTOR
Q6506 2SD601ARTX TRANSISTOR
Q6509 2SD601ARTX TRANSISTOR
Q6510 2SB709ARTX TRANSISTOR
Q6514 2SB709ARTX TRANSISTOR
Q6516 2SB709ARTX TRANSISTOR
Q6517 2SD601ARTX TRANSISTOR
Q6519 2SD601ARTX TRANSISTOR
RELAYS
RL801 TSEH8007 RELAY
RESISTORS
R002 ERJ6GEYJ182 RES,M 1.8K-J-1/10
R003 ERJ6GEYJ562 RES,M 5.6K-J-1/10
R004 ERDS1TJ122 RES,C 1.2K-J-1/2
R005 ERDS2TJ101 RES,C 100-J-1/4
R006 ERDS1TJ181 RES,C 180-J-1/2
R007 ERJ6GEYJ103 RES,M 10K-J-1/10
R008 ERJ6GEYJ103 RES,M 10K-J-1/10
R009 ERJ6GEYJ221 RES,M 220-J-1/10
R010 ERJ6GEYJ103 RES,M 10K-J-1/10
R012 ERJ6GEYJ103 RES,M 10K-J-1/10
R013 ERJ6GEYJ223 RES,M 22K-J-1/10
R014 ERJ6GEYJ472 RES,M 4.7K-J-1/10
