Panasonic CT-3207DF - Page 15

REPLACEMENT PARTS LIST
Models: CT-2707DF, CT-2707DUF, CT-27D12DF, CT-27D12DUF, CT-27D32F, CT-27D32UF, CT-3207DF, CT-3207DUF, CT-32D12DF,
CT-32D12DUF, CT-32D32F, CT-32D32UF, CT-36D12DF, CT-36D12DUF, CT-36D32F, CT-36D32UF, SP-3235F, SP-3235UF
Important Safety Notice: Components printed in BOLD TYPE have special characteristics important for safety. When replacing
any of these components use only manufacturer’s specified parts.
-15-
042-02
PARTS LIST
Parts List
C754 ECQB1H104JFW
CAP,P .1UF-J-50V
CT-3207DF/DUF CT-32D12DF/DUF
CT-32D32F/UF CT-36D12DF/DUF
CT-36D32F/UF SP-3235F/UF
C755 ECQB1H104JFW
CAP,P .1UF-J-50V
CT-3207DF/DUF CT-32D12DF/DUF
CT-32D32F/UF CT-36D12DF/DUF
CT-36D32F/UF SP-3235F/UF
C756 ECA1CM221B
CAP,E 10UF-16V
CT-3207DF/DUF CT-32D12DF/DUF
CT-32D32F/UF CT-36D12DF/DUF
CT-36D32F/UF SP-3235F/UF
C757 ECA1VM221B
CAP,E 220UF-35V
CT-3207DF/DUF CT-32D12DF/DUF
CT-32D32F/UF CT-36D12DF/DUF
CT-36D32F/UF SP-3235F/UF
C759 ECQE1395KNB
CAP,P 3.95UF-K-100V
CT-3207DF/DUF CT-32D12DF/DUF
CT-32D32F/UF CT-36D12DF/DUF
CT-36D32F/UF SP-3235F/UF
C760 TACCV101T50V
CAP,C 100PF/50V
CT-3207DF/DUF CT-32D12DF/DUF
CT-32D32F/UF CT-36D12DF/DUF
CT-36D32F/UF SP-3235F/UF
C801 ECKWAE472ZED CAP,C 4700PF-Z-500V
C802 ECKWAE472ZED CAP,C 4700PF-Z-500V
C803 ECKWAE472ZED CAP,C 4700PF-Z-500V
C804 ECKWAE472ZED CAP,C 4700PF-Z-500V
C805 EC0S2DA221BB
CAP,E 220UF/200V
CT-2707DF/DUF CT-27D12DF/DUF
CT-27D32F/UF
C805 EC0S2DA331BB
CAP,E 330UF/200V
CT-3207DF/DUF CT-32D12DF/DUF
CT-32D32F/UF SP-3235F/UF
C805 EC0S2DA471BB
CAP,E 470UF/160V
CT-36D12DF/DUF CT-36D32F/UF
C806 EC0S2DA221BB
CAP,E 220UF/200V
CT-2707DF/DUF CT-27D12DF/DUF
CT-27D32F/UF
C806 EC0S2DA331BB
CAP,E 330UF/200V
CT-3207DF/DUF CT-32D12DF/DUF
CT-32D32F/UF SP-3235F/UF
C806 EC0S2DA471BB
CAP,E 470UF/160V
CT-36D12DF/DUF CT-36D32F/UF
C807 ECA1HM2R2B CAP,E 2.2UF-50V
C808 ECA1CM101B CAP,E 100UF/16V
C809 EC0S2DG151DG CAP,E 151UF/200V
C810 ECQU2A153MVA CAP,P .015UF-M-250VAC
C811 ECQU2A153MVA CAP,P .015UF-M-250VAC
C812 ECQU2A224MVA CAP,P .22UF-M-250VAC
C814 ECQB1H823JF3 CAP,P .082UF-J-50V
C815 ECA1EHG101B
CAP,E 100UF-25V
CT-2707DF/DUF CT-3207DF/DUF
CT-27D12DF/DUF CT-27D32F/UF
CT-32D12DF/DUF CT-32D32F/UF
SP-3235F/UF
C815 ECA1VHG221B
CAP,E 220UF-35V
CT-36D12DF/DUF CT-36D32F/UF
REF
NO.
PART NO. DESCRIPTION
C818 ECKW3A821KBP CAP,C 820PF-K-1KVDC
C820 ECA1JHG100B CAP,E 10UF-63V
C821 ECKR2H152KB5 CAP,C .0015UF-K-500V
C822 ECA1EM221B CAP,E 220UF-25V
C823 ECA160V33UE CAP,E 33UF/160V
C824 ECKW3A331KBP CAP,C 330PF-K-1KV
C825 ECKW3A471KBP CAP,C 470PF-K-1KV
C904 TACCX103T50V
CAP,C .01UF/50V
CT-36D12DF/DUF CT-36D32F/UF
C952 ECA1CM100B
CAP,E 10UF-16V
CT-36D12DF/DUF CT-36D32F/UF
C953 TACCX103T50V
CAP,C .01UF/50V
CT-36D12DF/DUF CT-36D32F/UF
C954 TACCX103T50V
CAP,C .01UF/50V
CT-36D12DF/DUF CT-36D32F/UF
C958 ECA2EM100B
CAP,E 10UF/250V
CT-36D12DF/DUF CT-36D32F/UF
C959 ECKW2H472MD8
CAP,C 4700PF-M-500V
CT-36D12DF/DUF CT-36D32F/UF
C961 ECA2CM100B
CAP,E 10UF-160V
CT-36D12DF/DUF CT-36D32F/UF
C962 ECKW2H472MD8
CAP,C 4700PF-M-500V
CT-36D12DF/DUF CT-36D32F/UF
C964 ECA0JM101B
CAP,E 100UF-6.3V
CT-36D12DF/DUF CT-36D32F/UF
C966 ECA0JM101B
CAP,E 100UF-6.3V
CT-36D12DF/DUF CT-36D32F/UF
C967 ECA1CM221B
CAP,E 10UF-16V
CT-36D12DF/DUF CT-36D32F/UF
C968 TACCX103T50V
CAP,C .01UF/50V
CT-36D12DF/DUF CT-36D32F/UF
C969 TACCX103T50V
CAP,C .01UF/50V
CT-36D12DF/DUF CT-36D32F/UF
C970 ECCR2H151K5
CAP,C 150-10-500V
CT-36D12DF/DUF CT-36D32F/UF
C971 TACCW151T50V
CAP,C 150PF/50V
CT-36D12DF/DUF CT-36D32F/UF
C1801 TCJ2VF1H103Z
CAP,C .01UF-Z-50V
CT-2707DF/DUF CT-3207DF/DUF
CT-27D32F/UF CT-32D32F/UF CT-
36D32F/UF SP-3235F/UF
C1802 ECQV1H154JL3
CAP,P.15UF-J-50V
CT-2707DF/DUF CT-3207DF/DUF
CT-27D32F/UF CT-32D32F/UF
CT-36D32F/UF SP-3235F/UF
C1803 ECA1HMR22B
CAP,E .22UF-50V
CT-2707DF/DUF CT-3207DF/DUF
CT-27D32F/UF CT-32D32F/UF
CT-36D32F/UF SP-3235F/UF
C1804 ECEA1HKAR22B
CAP,E .22UF-50V
CT-2707DF/DUF CT-3207DF/DUF
CT-27D32F/UF CT-32D32F/UF
CT-36D32F/UF SP-3235F/UF
C1805 TCJ2VF1H333Z
CAP,C .033UF-Z-50V
CT-2707DF/DUF CT-3207DF/DUF
CT-27D32F/UF CT-32D32F/UF
CT-36D32F/UF SP-3235F/UF
REF
NO.
PART NO. DESCRIPTION
